Legion TWWT-30MV Steam Kettles
Description
Legion TWWT-30 Direct Steam Tilting Wall-Mount Kettle with MV Mixer – 30 gal
304 Stainless Steel • 2/3 Jacket • 30 psi Operating PressureEngineered for high-volume kitchens that refuse to compromise on consistency, the Legion TWWT-30 combines rock-solid 304 stainless steel construction with a powerful two-speed MV twin-shaft mixer. Wall-bracket mounting saves valuable floor space while the self-locking worm-gear tilt puts 114 litres of perfectly blended product within effortless reach.
Key Kettle Features
- Seamless deep-drawn 304 stainless steel liner resists pitting and eliminates hard-to-clean crevices.
- 304L stainless 2/3 jacket ensures rapid, even heating from an external steam source (30 psi max).
- Self-locking worm-gear tilt mechanism allows precise, drip-free pouring at any angle.
- Heavy-duty 304 stainless support arms are seam-welded to the jacket for superior rigidity.
- Wall-bracket design opens floor space and simplifies cleaning beneath the unit.
- Reinforced stainless steel gear box built to handle continuous institutional use.
- ASME-code stamped and NSF certified; proudly made in the USA.
Integrated MV Twin-Shaft Mixer
- Two-speed gear motor (High 46 rpm / 120 rpm, Low 23 rpm / 60 rpm) matched to 30-gal capacity.
- 304 stainless anchor-style main agitator hugs the kettle wall for thorough circulation.
- Secondary counter-rotating beater breaks up lumps and speeds heat transfer.
- Removable, dishwasher-safe nylon scraper blades continuously clean the entire heated surface.
- Bayonet-mount agitators release in seconds for cleaning or when an unobstructed kettle is desired.
- Actuator-assisted bridge lift with positive rim-lock keeps the mixer perfectly aligned and secure.
- Safety interlock prevents high-speed starts when the bridge is raised.
Dimensions & Utilities
| Capacity | 30 gal (114 L) |
|---|---|
| Interior Diameter (A) | 23 in / 584 mm |
| Wall Projection (B) | 20.3 in / 516 mm |
| Overall Height (F) | 42.5 in / 1080 mm (with mixer bridge lowered) |
| Tilt Clearance (X) | 24.8 in / 630 mm minimum pour path |
| Steam Connection | ¾ in NPT inlet • ½ in NPT condensate outlet |
| Operating Pressure | 30 psi (2.1 bar) max |
| Electrical (Mixer) | 1 HP / ½ HP, 208-230/460 V, 50/60 Hz, 1- or 3-phase |
| Mounting Bracket Span (Y × Z) | 14.3 in × 30.6 in |
| Net Weight | Factory-quoted shipping weight consult sales for current figure |
Ideal Applications
- Soups, sauces & gravies that demand constant agitation
- Custards, puddings and other delicate dairy products
- Chili, stews and high-protein meals needing gentle, uniform heating
- Institutional batch cooking for schools, healthcare and correctional facilities
What’s Included
- TWWT-30 2/3-jacketed tilting kettle with wall bracket and control console
- Factory-installed MV twin-shaft mixer assembly with lift mechanism
- Owner’s manual & ASME/NSF compliance documentation
Looking for additional options such as draw-off valves, automatic water fill, or higher steam pressures? Contact our sales team for custom-configured Legion kettles.
