Legion TWWT-100MV Steam Kettles
Description
Legion TWWT-100MV 100-Gal Wall-Mount Tilting Steam Kettle with Two-Speed Mixer
Direct Steam · 2/3 Jacketed · 30 psiEngineered for high-volume commissaries, central kitchens and correctional facilities, the Legion TWWT-100MV unites a massive 100-gallon tilting kettle with an integrated two-speed twin-shaft agitator—delivering rapid heat-up, uniform product consistency and operator-preferred ergonomics in one space-saving wall-mounted package.
Key performance advantages
- 2/3 steam jacket rated at 30 psi provides even, high-efficiency heating and fast recovery.
- Seamless deep-drawn 304 stainless steel liner and 304L jacket resist pitting and simplify cleanup.
- Heavy-duty twin-shaft mixer:
- Anchor-style main agitator hugs the kettle wall to prevent scorching.
- Counter-rotating secondary beater breaks up lumps for ultra-smooth textures.
- Two-speed gear motor (Low 23 rpm / High 46 rpm main shaft) handles delicate sauces to thick fillings.
- Removable nylon scraper blades continuously clean the entire kettle surface.
- Self-locking worm-gear tilt mechanism offers smooth, controlled pouring from a safe work height.
- 304 stainless support arms are seam-welded to the jacket for rugged, permanent wall mounting.
- Totally enclosed stainless control console protects steam and electrical connections.
- Built in the USA to ASME & NSF standards.
Specifications
| Model | TWWT-100MV |
|---|---|
| Capacity | 100 gal / 379 L |
| Cooking jacket | 2/3 coverage, 304L stainless |
| Operating pressure | 30 psi (2.07 bar) max |
| Mounting style | Wall-bracket, tilting |
| Tilt mechanism | Self-locking worm gear with hand wheel |
| Steam connection | 3/4" NPT inlet & outlet |
| Agitator motor | 2 HP, totally enclosed, two-speed |
| Main agitator speed | Low 23 rpm | High 46 rpm |
| Secondary beater speed | Low 60 rpm | High 120 rpm |
| Overall width (A) | 39.0" |
| Overall height (F) | 58.8" |
| Recommended mount height (T) | 24.1" |
| Minimum pour path (X) | 35.4" |
Dimensions taken from Legion Revision 113 drawings. Request a certified drawing for final rough-in and utility connection information.
Ideal applications
- Soups, stews, chili and chowders
- High-volume sauces and gravies
- Custards, puddings and thick dessert fillings
- Cook-chill or cook-freeze production lines
Popular options & accessories (sold separately)
- 2" or 3" sanitary draw-off valve
- Single or dual water fill faucets with 12" / 18" swing nozzles
- 48" rinse hose (vinyl or stainless)
- Automatic water meter
- Lift-off or actuator-assisted one-piece cover
- Basket, tri-basket or nylon bag inserts
Backed by Legion’s one-year parts & labor warranty with optional extended coverage.
