Legion TWWC-80 Direct Steam Tilting Wall-Mount Kettle with 2-Speed Mixer – 80 gal
Deep-drawn 304 stainless steel • 2/3 jacket • 30 psiBuilt for today’s high-volume kitchens, the Legion TWWC-80 pairs an 80-gallon direct-steam kettle with an integrated twin-shaft agitator. The wall-console design frees up valuable floor space while delivering perfectly heated and thoroughly mixed batches shift after shift.
Kettle Highlights
- Seamless deep-drawn 304 stainless steel liner for superior sanitation and longevity.
- 2/3 jacketed body delivers rapid, even heating up to 30 psi operating pressure.
- Self-locking worm-gear hand-tilt allows precise, splash-free pouring at any angle.
- Heavy-duty 304 stainless wall support consoles with rear utility connections keep plumbing hidden and protected.
- Made in the USA and manufactured to ASME & NSF standards.
Integrated Twin-Shaft Mixer
- Two-speed gear motor (Low 23 RPM / High 46 RPM on main agitator) tackles delicate soups to thick sauces.
- 304 stainless anchor agitator contours the kettle wall for complete product movement.
- Counter-rotating beater (60 / 120 RPM) breaks up lumps and accelerates mixing.
- Removable nylon scraper blades constantly clean the kettle surface to prevent scorching.
- Actuator-assisted lift raises the bridge, agitator and scraper for effortless cleaning or kettle-only use.
- Quick-lock rim latch with safety interlock prevents high-speed starts while the bridge is raised.
Ideal For
- Bulk soups, stocks & stews
- High-volume sauces, gravies & roux
- Pasta, rice & cereal production
- Custards, puddings and other viscous desserts
Key Specifications
| Capacity | 80 gal / 303 L |
|---|---|
| Operating Pressure | 30 psi (2.1 bar) |
| Construction | Seamless 304 stainless liner & 304L stainless jacket |
| Jacket Coverage | 2/3 of kettle body |
| Mounting | Wall-console; stainless reinforced boxes with rear connections |
| Tilting Mechanism | Manual self-locking worm-gear |
| Steam Connections | 3/4" NPT inlet & outlet |
| Main Agitator Speeds | Low 23 RPM / High 46 RPM |
| Secondary Beater Speeds | Low 60 RPM / High 120 RPM |
| Mixer Motor | 1 HP (low) / 2 HP (high), totally-enclosed gear motor |
| Overall Width | Approx. 39.6 in (1,006 mm) |
| Overall Depth | Approx. 27.4 in (696 mm) |
| Overall Height to Rim | Approx. 30.5 in (775 mm) |
Looking for a draw-off valve, water-fill faucet or other accessories? Reach out and we’ll configure this kettle to fit your exact production needs.
Product Weight:
906.0 lbFrequently Asked Questions
