Legion TWWC-60MV Steam Kettles
Description
Legion TWWC-60 Wall-Mount Tilting Kettle with 2-Speed Mixer – 60 Gal / 227 L
304 SS • 2/3 Jacket • Direct-Steam • 30 psi • Made in USAMaximize production while freeing up floor space with Legion’s TWWC-60. This 60-gallon wall-console kettle pairs precision tilting and rugged 2-speed agitation to deliver perfectly-blended soups, sauces, fillings, stews and more in record time.
Why chefs choose the TWWC-60
- Seamless deep-drawn 304 stainless steel liner – no crevices, pitting or weld seams to trap food.
- 2/3 steam jacket surrounds the sidewall & bottom for lightning-fast, even heating up to 30 psi.
- Self-locking worm-gear tilt lets one operator pour with fingertip control and locks automatically for safety.
- Twin-shaft MV mixer with anchor agitator, nylon scraper blades & counter-rotating beater keeps every ounce in motion – no scorching, no hotspots.
- Two-speed gear motor (23 rpm low / 46 rpm high) tackles delicate dairy one minute and thick chili the next.
- Bayonet-mounted agitator & beater lift out in seconds for cleaning or stationary kettle use.
- Wall-console mounting saves valuable floor real estate while heavy-duty stainless consoles house all plumbing and controls out of the splash zone.
- Rear steam connections keep utility lines hidden for a cleaner, safer cookline.
- Made in the USA and built to ASME and NSF standards for long-term, trouble-free service.
Technical specifications
| Model | TWWC-60 (with factory-installed MV mixer) |
|---|---|
| Capacity | 60 gal | 227 L |
| Heating source | Direct steam, 2/3 jacket, 30 psi max. operating pressure |
| Liner / Jacket material | Seamless 304 SS liner / 304L SS jacket |
| Tilt mechanism | Manual, self-locking worm gear with balanced handle |
| Mounting style | Wall-console, stainless reinforced support boxes |
| Mixer type | Twin-shaft anchor agitator + counter-rotating beater, nylon scrape blades |
| Agitator speeds | Low 23 rpm / High 46 rpm (main) | 60 / 120 rpm (secondary) |
| Motor ratings | ¾ HP (low) / 1½ HP (high) – totally-enclosed gear motor |
| Overall dimensions |
A 29.5″ B 25.0″ C 41.5″ D 25.1″ E 27.9″ H 13.5″ Minimum pour path (X) 35.5″ |
| Steam connections | ¾″ NPT inlet / ½″ NPT outlet (rear) |
| Certifications | ASME Section VIII, NSF |
What’s included
- Factory-installed MV twin-shaft mixer head with lift-assist
- Removable agitator, beater & scraper blades
- Rear-mounted steam inlet & condensate outlet stubbed to consoles
- All control & support consoles in reinforced 304 stainless steel
- Comprehensive owner’s manual & Legion one-year parts & labor warranty
Popular add-ons (sold separately): draw-off valve kits, fill faucets, spray hose assemblies, automatic water meters, in-wall carrier brackets, lift-off or actuator-assisted covers and more – contact us for a custom quote.
From scratch stocks to high-viscosity fillings, the Legion TWWC-60 with integrated mixer gives you the capacity, consistency and control you need – all in a space-saving wall-mount package built to outlast the busiest kitchen. Ready to elevate production? Add the TWWC-60 to your cart and experience the Legion advantage.
