Legion TWWC-50MV Steam Kettles
Description
Legion TWWC-50 Direct-Steam Tilting Wall-Mounted Kettle w/ MV Mixer – 50 gal
304 Stainless Steel | 2/3 Jacket | 30 psi | Made in USABuilt for demanding production kitchens, the 50-gallon Legion TWWC-50 pairs rapid, even direct-steam heating with a powerful twin-shaft mixer and a space-saving wall console. The result is faster cook times, consistent product quality and effortless pour-off—all from a single, stainless-steel workhorse.
Why You’ll Love It
- Seamless deep-drawn 304 SS kettle liner cleans easily and resists pitting.
- 2/3 jacketed body heats up quickly using facility steam up to 30 psi.
- Self-locking worm-gear tilt offers smooth, precise pouring by one operator.
- MV twin-shaft mixer (two-speed) keeps thick or delicate recipes perfectly blended; nylon scraper prevents burn-on.
- Reinforced stainless wall consoles hide rear-facing steam & condensate lines for a cleaner work zone.
- ASME & NSF compliant—engineered and manufactured in Waynesboro, GA.
MV Mixer Highlights
- Balanced aluminum bridge with totally enclosed gear motor.
- 304 SS anchor agitator hugs kettle wall; removable nylon blades scrape entire surface.
- 304 SS counter-rotating beater boosts heat transfer and product consistency.
- Bayonet-mount shafts lift out in seconds for cleaning or kettle-only use.
- Actuator-assisted lift plus quick-acting rim lock for operator safety.
Technical Specifications
| Capacity | 50 US gal / 189 L |
|---|---|
| Kettle Construction | 304 SS seamless liner / 304L SS jacket |
| Jacket Coverage | 2/3 of kettle body |
| Operating Pressure | 30 psi (ASME stamped) |
| Mounting Style | Wall-console; stainless reinforced support boxes |
| Tilt Mechanism | Self-locking worm-gear hand crank |
| Steam Connections | ¾" NPT inlet / ½" NPT outlet (rear) |
| Mixer Type | Twin-shaft, 2-speed |
| Mixer RPM* | High 46 RPM / Low 23 RPM (main agitator) |
| Mixer Horsepower* | High 2 HP / Low 1 HP |
| Origin | Made in USA – Legion Industries, Waynesboro GA |
*Based on standard 15:1 gear head ratio and 2.6:1 agitator-to-beater ratio.
Perfect For
- Central & commissary kitchens
- High-volume restaurants and hotels
- Food processors, saucemakers & ready-meal producers
- Catering operations and institutions
Popular Accessories (sold separately)
- Single or double fill faucet with 12" / 18" swing nozzle
- 48" flexible spray hose (vinyl or stainless)
- 2" or 3" draw-off valves (compression or ball-type)
- Basket inserts, pour-lip pan holder & measuring strip
- Air eliminator or pressure-reducing valves
