Legion 40-Gallon Direct Steam Tilting Wall-Mount Kettle with 2-Speed Mixer
Model TWWC-40-MV | Made in USABuilt for high-volume, high-precision production, the Legion TWWC-40-MV combines a rugged 40-gallon 2/3-jacketed kettle with a powerful twin-shaft agitator. From silky sauces to hearty soups and fillings, you’ll finish batches faster, more consistently, and with less labor.
Key Performance Features
- 40 gal / 151 L working capacity – ideal for central kitchens, commissaries & institutions
- Seamless deep-drawn 304 stainless steel liner for exceptional durability and easy sanitation
- 2/3 steam jacket (304L stainless) rated 30 psi for rapid, even heating
- Twin-shaft, 2-speed agitator:
- Anchor-style main agitator follows kettle contour
- Counter-rotating secondary beater improves product movement
- Removable nylon scraper blades keep surfaces clean and prevent burn-on
- High speed 46 RPM / Low speed 23 RPM (main shaft)
- Enclosed gear motor (1 ½ HP high | ¾ HP low) with right-angle drive – quiet, reliable power
- Self-locking worm-gear tilt with insulated handle for safe, controlled pouring
- Stainless steel reinforced support consoles with rear plumbing connections keep the work zone clear
- Actuator-assisted lift lets one operator raise the agitator bridge effortlessly for cleaning or batch change-over
- Positive rim lock & safety interlock prevent high-speed starts when the bridge is raised
- Conforms to ASME & NSF standards
Technical Specifications
| Model | TWWC-40-MV |
|---|---|
| Capacity | 40 gal (151 L) |
| Jacket Type / Pressure | 2/3 jacket, 30 psi (steam) ¾″ NPT inlet · ½″ NPT outlet |
| Kettle Construction | Seamless 304 SS liner & 304L SS jacket |
| Mounting | Wall-console, rear utility connections |
| Tilt Mechanism | Self-locking worm gear, manual crank |
| Agitator System | Twin-shaft, 2-speed (46 / 23 RPM main) Anchor agitator + counter-rotating beater |
| Agitator Motor | 1 ½ HP (high) / ¾ HP (low), TEFC gear motor |
| Overall Height | 30 ½″ (bridge lowered) |
| Minimum Pour Path | 35 ½″ |
| Origin | Waynesboro, Georgia — USA |
Designed for Everyday Efficiency
- Deep-drawn bowl edges eliminate hard-to-clean crevices
- Rear plumbing connections keep hoses and valves off the kitchen floor
- Quick-release bayonet mounts let you remove agitator tools in seconds
- Optional draw-off valve or water-fill faucet kits available to fit your workflow
Direct steam kettles require an external steam source sized for 30 psi operation. Consult your boiler manufacturer for capacity requirements.
Product Weight:
714.0 lbFrequently Asked Questions
