Legion TWWC-30MV 30 gal Direct Steam Tilting Wall-Mount Kettle with 2-Speed Mixer
2/3-Jacket • 304 SS Liner • 30 psi • Made in USABuilt for demanding production kitchens, the Legion TWWC-30MV combines rapid, even steam heating with hands-free mechanical agitation—all in a space-saving wall-console design that tilts effortlessly for complete product evacuation.
Why You’ll Love It
- 30 gallon (114 L) capacity—ideal for batch soups, sauces, fillings, custards and more.
- Seamless deep-drawn 304 stainless steel kettle liner resists pitting, corrosion and flavor transfer.
- 2/3 jacketed design delivers fast, uniform heat with no hot spots; rated 30 psi for high-output production.
- Self-locking worm-gear tilt mechanism provides precise pour control while keeping the kettle exactly where you set it.
- Reinforced 304 stainless steel wall-mount consoles hide all plumbing and steam connections at the rear for a clean, code-friendly installation.
- Control console with clearly marked switches and 2-speed selector for the integrated mixer.
- NSF, ASME-code and UL/ETL compliant; manufactured and assembled in Waynesboro, Georgia.
Built-In 2-Speed Mixing System
- Twin-shaft agitator with 304 SS anchor arm hugs the kettle contour for thorough circulation.
- Removable nylon scraper blades continuously clean the sidewalls to help prevent scorching.
- Counter-rotating 304 SS beater breaks up particulates and improves heat transfer.
- Quick-release bayonet mounts let you remove agitator and beater in seconds for sanitation or when using the kettle without mixing.
- Actuator-assisted lift raises the entire mixer bridge clear of the rim for unobstructed access.
- Safety interlock blocks high-speed starts until the bridge is fully seated and latched.
Technical Specifications
| Model | TWWC-30MV |
|---|---|
| Capacity | 30 gal | 114 L |
| Heating Source | Direct steam, 30 psi max |
| Kettle Construction | 304 SS liner, 304L seamless jacket |
| Jacket Coverage | 2/3 (bottom & sidewalls) |
| Tilt Mechanism | Manual self-locking worm gear, 50° pour path |
| Steam Connections | Inlet ¾″ NPT • Outlet ½″ NPT (rear) |
| Installed Mixer | Legion MV twin-shaft, 2-speed |
| Mixer Motor | High 1 HP | Low ½ HP (totally enclosed gear-motor) |
| Mixer Speed |
High 46 rpm main / 120 rpm beater Low 23 rpm main / 60 rpm beater |
| Overall Width (A) | 23.0″ / 584 mm |
| Overall Height (C) | 41.3″ / 1 049 mm |
| Wall Projection (D) | 21.5″ / 546 mm |
| Shipping Weight | Approx. 450 lb / 204 kg |
| Warranty | 12-month parts & labor (extended plans available) |
Popular Factory Options
- 2″ or 3″ sanitary draw-off valve with compression or ball-type fitting
- Single or dual high-flow fill faucets (12″ or 18″ swing nozzles)
- 48″ flexible spray hose / rinse gun assembly
- Automatic water-metered fill system
- Lift-off or actuator-assisted cover
- Basket, pour-lip and measuring accessories
Contact us for lead times, voltage selections and complete option lists.
Product Weight:
697.0 lbFrequently Asked Questions
