TWWC-20 Direct Steam Tilting Wall-Mount Kettle with Integrated MV Mixer – 20 Gal.
304 SS Seamless Liner • 2/3 Jacket • 30 psi • Made in USABuilt for high-volume, high-speed production, the Legion TWWC-20 combines a 20-gallon 2/3-jacketed direct-steam kettle with a powerful twin-shaft MV mixer. From scratch sauces and soups to delicate creams and custards, this wall-mounted workhorse delivers consistent results while saving space and labor.
Key Features & Benefits
- Seamless deep-drawn 304 stainless steel kettle liner for maximum sanitation and easy cleaning.
- 2/3 jacket coverage in 304L stainless ensures rapid, uniform heat transfer.
- Rated 30 psi operating pressure for faster heat-up and higher production throughput.
- Self-locking worm-gear tilt mechanism allows smooth, controlled pouring at any angle.
- Wall-console mount with stainless reinforced support consoles keeps the floor clear and simplifies wash-down.
- Rear-facing steam, water and electrical hookups streamline installation and maintain a clutter-free work zone.
- ASME-code construction; NSF compliant – engineered, built and certified in the USA.
MV Twin-Shaft Mixer Highlights
- Two-speed gear motor (low 23 rpm / high 46 rpm main agitator) matched to 20 gal. capacity.
- Counter-rotating secondary beater (60 rpm / 120 rpm) eliminates dead spots for even product consistency.
- 304 SS anchor agitator hugs kettle contour; removable nylon scraper blades wipe the sidewall and bottom clean every revolution.
- Bayonet-mount agitator & beater lift out in seconds for thorough sanitation or kettle-only operation.
- Actuator-assisted lift raises the entire bridge, scraper and agitator with minimal effort.
- Positive rim-lock and safety interlock prevent high-speed starts when the bridge is raised or unlocked.
Technical Specifications
| Capacity | 20 gal / 76 L |
|---|---|
| Inner Liner | Seamless 304 stainless steel, deep-drawn |
| Jacket | 2/3 jacket, 304L stainless steel |
| Operating Pressure | 30 psi (207 kPa) max. |
| Tilt Mechanism | Self-locking worm gear, manual crank |
| Mounting Style | Wall-console, stainless reinforced support consoles |
| Steam Connections | ¾" NPT inlet | ½" NPT condensate outlet (rear) |
| Overall Width (C) | 39 in (991 mm) |
| Overall Height (T) | 28 in (711 mm) to top of kettle rim |
| Overall Depth (X) | 33 in (838 mm) minimum pour path |
| Agitator Motor | 1 HP high speed / ½ HP low speed, 2-speed, TEFC |
| Main Agitator Speeds | Low 23 rpm · High 46 rpm |
| Secondary Beater Speeds | Low 60 rpm · High 120 rpm |
Ideal Applications
- Soups, stews & chilis
- Custards, puddings & pastry fillings
- Sauces, gravies & roux
- Pasta & rice cooking
- Scratch-made beverage bases & syrups
Warranty & Compliance
12-month parts & labor warranty standard. Built to meet or exceed ASME, NSF and other applicable agency requirements.
Product Weight:
648.0 lbFrequently Asked Questions
