Legion 100-Gallon Direct Steam Tilting Wall-Mount Kettle with 2-Speed Mixer
Model TWWC-100-MV | 2/3 Jacketed • 304 Stainless Steel • 25 psiPurpose-built for high-volume commissaries, correctional kitchens and institutional foodservice, the Legion TWWC-100 combines 100 gallons of steam-powered cooking capacity with an integrated two-speed twin-shaft agitator. The result is faster batch times, superior product consistency and a cleaner, more efficient workspace.
Key Performance Advantages- 2/3 jacketed direct-steam heating rated at 25 psi (≈298 °F) for rapid, uniform heat transfer.
- Seamless, deep-drawn 304 stainless steel liner and 304L jacket resist pitting, corrosion and flavor carry-over.
-
Twin-shaft MV mixer (2 hp high / 1 hp low):
– Anchor-style main agitator with removable nylon scraper blades cleans the sidewalls and kettle floor.
– Counter-rotating secondary beater breaks up lumps for ultra-smooth sauces, soups and fillings.
– Two-speed gearbox (46 rpm / 23 rpm main shaft) matched to 120 rpm / 60 rpm secondary beater for optimal shear control. - Actuator-assisted bridge & agitator lift plus quick-acting rim lock for fast kettle access and tool-free cleaning.
- Self-locking worm-gear tilt lets one operator safely pour up to 100 gal with precise, controlled dispensing.
- Heavy-duty stainless steel support consoles with rear steam & condensate connections keep the front clear and simplify wall mounting.
- Totally enclosed gear motor and sealed mixer bridge protect critical components from steam and wash-downs.
- Fabricated, assembled and ASME-code stamped in the USA.
| Capacity | 100 gal | 379 L |
|---|---|
| Heating Jacket | 2/3 jacket, direct steam |
| Operating Pressure | 25 psi (172 kPa) |
| Kettle Construction | Seamless 304 SS liner & 304L jacket, satin finish |
| Mounting Style | Wall-console (in-wall carrier optional) |
| Tilt Mechanism | Manual, self-locking worm gear with fold-down handle |
| Agitator Motor | 2 hp (high) / 1 hp (low) totally-enclosed gear motor |
| Agitator Speeds* | Main: 46 rpm / 23 rpm Beater: 120 rpm / 60 rpm |
| Steam Connections | ¾″ NPT inlet, ¾″ NPT outlet (rear) |
| Overall Dimensions** | Width 44.5″ • Depth 35.4″ • Height 41.3″ |
| Net Weight | ≈ 1,325 lb / 601 kg (kettle & mixer) |
*Based on standard 15:1 gear-head ratio.
**Height varies slightly depending on draw-off and faucet selections.
- Control console with start/stop, speed selector and emergency stop.
- Positive rim latch & agitator safety interlock (prevents high-speed starts when bridge is raised).
- Rear-mounted steam and condensate plumbing (fittings installed).
- Sanitary 2” draw-off valve with compression fitting.
- Stainless steel tri-leg support foot.
- Comprehensive owner’s manual & Legion one-year parts & labor warranty.
- Automatic water fill meter
- 12″ or 18″ swing-nozzle fill faucet (single or double arm)
- 48″ flexible spray hose assembly
- Pressure-reducing valve or air eliminator
- Lockable lid, measuring strip & kettle care kit
Product Weight:
1000.0 lbFrequently Asked Questions
