Legion TWU-40MV Steam Kettles
Description
Legion TWU-40 Direct-Steam Tilting Kettle with 2-Speed Mixer
40 Gallon | 304 Stainless Steel | 2/3 Jacket | Made in USAPurpose-built for busy production kitchens, the TWU-40 pairs Legion’s legendary deep-drawn kettle with a powerful twin-shaft agitator, giving you fast, even heating and hands-free mixing in one compact station. Batch after batch of soups, sauces, fillings or confectionery cooks consistently and pours cleanly—saving labor, floor space and energy.
Top Benefits
- 40 gal (151 L) capacity—perfect for medium-volume restaurants, commissaries & schools.
- 2/3 jacketed, direct-steam design delivers lightning-fast heat transfer up to 30 psi without hotspots.
- Seamless 304 SS kettle liner + 304L jacket—no interior welds, no crevices, no hassle when cleaning.
- Twin-shaft MV agitator (two-speed)
- Anchor-style main agitator hugs the contour for complete product movement.
- Counter-rotating beater breaks up lumps and prevents burn-on.
- Nylon scrape blades sweep every inch of the sidewall & floor.
- High speed 46 RPM / 120 RPM • Low speed 23 RPM / 60 RPM (main / secondary).
- Bayonet mounts lift out in seconds for ware-washing.
- Self-locking worm-gear tilt—smooth, incremental pour control with zero back-drive.
- Reinforced 304 SS gear box & control console built to thrive in high-heat, high-moisture environments.
- 2″ tubular U-frame with adjustable flanged feet for rock-solid, easy-to-level installation.
- ASME-, NSF- & UL-compliant—meets today’s strictest code and inspection requirements.
Technical Specifications
| Model | TWU-40-MV |
|---|---|
| Capacity | 40 gal / 151 L |
| Operating Pressure | 30 psi (steam jacket) |
| Jacket Coverage | Two-thirds of kettle body |
| Construction | Seamless 304 SS liner & 304L SS jacket |
| Agitator Motor | 1½ HP high / ¾ HP low, totally-enclosed gear motor |
| Agitator Speeds | High 46 RPM & 120 RPM • Low 23 RPM & 60 RPM |
| Tilt Mechanism | Manual, self-locking worm gear |
| Steam Connections | ¾″ NPT inlet • ½″ NPT outlet |
| Key Dimensions | A 25.5″ • B 22.3″ • C 41.5″ • L 33.5″ (see drawing for full dimensional data) |
| Support Frame | 2″ 304 SS tubular U-frame with adjustable flanged feet |
| Country of Origin | USA (Waynesboro, GA) |
| Warranty | 12-month parts & labor (extended coverage available) |
Why Operators Love It
- Saves labor—automatic mixing eliminates constant stirring and product monitoring.
- Saves energy—deep-drawn kettle wall maximizes heat exchange for faster heat-up.
- Saves downtime—tool-free agitator removal and seamless interior slash cleaning time.
- Saves space—cook, mix, finish & pour from a single footprint.
Need a draw-off valve, faucet package or security options? Talk to our team—Legion offers a full menu of factory-installed accessories so the TWU-40 ships 100 % production-ready.
