Legion TWT-80 Direct Steam Tilting Kettle with 2-Speed MV Mixer
80 gal / 303 L • 2/3-jacketed • 304 SS • 30 psi • Made in USABuilt for kitchens that refuse to compromise on speed, consistency or sanitation, the Legion TWT-80 pairs an 80-gallon deep-drawn kettle with a powerful twin-shaft agitator. Rapid direct-steam heating, hands-free mixing and rock-solid stainless construction let you batch soups, sauces and fillings faster—without the scorch, splatter or manual stirring.
Kettle performance & construction
- Seamless 304 stainless steel liner—no crevices for food soil or bacteria.
- 304L stainless 2/3 steam jacket blankets sidewall & bottom for uniform heating.
- Rated 30 psi for connection to most boiler systems.
- Self-locking worm-gear hand tilt—smooth, precise and secure at any angle.
- Reinforced stainless gear box & control console protect critical components.
- 2" tubular tri-leg frame with adjustable flanged feet keeps the vessel level on uneven floors.
- ASME-stamped & NSF-listed; manufactured in Waynesboro, GA.
Integrated MV twin-shaft mixer
- Two-speed TEFC gear motor: 23 / 46 rpm main agitator, 60 / 120 rpm beater.
- Anchor-style agitator hugs kettle contour; removable nylon blades continuously scrape wall & bottom.
- Counter-rotating 304 SS secondary beater eliminates hot spots & promotes even particulate suspension.
- Actuator-assisted bridge lift plus bayonet-mount tools for lightning-fast cleaning.
- Positive rim lock and safety interlock prevent high-speed starts when raised.
Ideal menu applications
- Soups, chowders & bone broths
- Chili, stews & curries
- Cheese & cream sauces
- Puddings, custards & fruit fillings
- Jam, jelly & confectionery syrups
Key specifications
| Capacity | 80 gal (303 L) |
|---|---|
| Interior liner | Seamless 304 stainless steel |
| Jacket coverage | 2/3 side & bottom, 304L stainless |
| Jacket pressure rating | 30 psi / 135 °C (275 °F) |
| Steam inlet / outlet | ¾" NPT (both) |
| Tilt mechanism | Hand-crank, self-locking worm gear |
| Frame | 2" tubular tri-leg, 304 SS, adjustable flanged feet |
| Mixer motor | 2 HP (high) / 1 HP (low), totally-enclosed gear drive |
| Mixer speeds | 23 / 46 rpm agitator • 60 / 120 rpm beater |
| Overall width (F) | 53.3" / 135 cm |
| Overall depth (G) | 38.3" / 97 cm |
| Pour-path clearance (X) | 31.6" / 80 cm minimum |
| Origin | Waynesboro, Georgia, USA |
Looking for custom accessories, higher pressures or different voltages? Legion builds each TWT kettle to order—contact us for tailored solutions that fit your line.
