Legion 30-Gallon Direct Steam Tilting Kettle with 2-Speed Mixer
Model TWT-30 MV | 2/3-Jacketed • Floor-Mounted • Made in USAEngineered for high-volume, scratch cooking, the Legion TWT-30 MV combines rapid, even steam heating with a powerful twin-shaft agitator—making it the perfect workhorse for soups, sauces, stews, confectionery fillings and more.
Key Product Highlights
- 30 gal (114 L) working capacity with seamless, deep-drawn 304 SS liner for maximum sanitation.
- 2/3-jacketed 304L stainless steel shell—ASME stamped for 30 psi direct steam operation.
- Self-locking worm-gear tilt mechanism for smooth, controlled pouring through the full pour path.
- Reinforced stainless gear box and large hand wheel—built to handle heavy, high-viscosity batches.
- Tri-leg, 2" tubular stainless frame with adjustable flanged feet for rock-solid, level installation.
- Compact control console keeps steam and mixer switches within easy reach while protecting components.
- Complies with ASME, NSF and other applicable standards; manufactured and factory-tested in Waynesboro, GA.
Integrated 2-Speed Twin-Shaft Mixer
- Anchor-style primary agitator in 304 SS hugs the kettle wall for thorough heat transfer.
- Removable nylon scraper blades continuously wipe the interior—reducing scorching and cleanup time.
- Counter-rotating secondary beater breaks up particulates and promotes uniform, lump-free products.
- Factory-set dual speeds:
- Main agitator – Low 23 RPM / High 46 RPM
- Secondary beater – Low 60 RPM / High 120 RPM
- Actuator-assisted bridge lift plus quick bayonet mounts for fast removal and sanitation.
- Built-in safety interlock prevents accidental high-speed starts when blades are raised.
Perfect For
- Stocks, broths and chowders
- Tomato, cream or béchamel-based sauces
- Fruit fillings, jams and preserves
- Confectionery syrups & fondants
- Custards, puddings and pastry creams
- Chili, curries and other hearty entrées
Technical Specifications
| Capacity | 30 gal / 114 L |
|---|---|
| Operating Pressure | 30 psi (2.1 bar) maximum, direct steam |
| Construction | Seamless 304 SS liner & 304L jacket, deep-drawn |
| Jacket Coverage | 2/3 kettle body |
| Frame | 2" tubular stainless tri-leg, adjustable flanged feet |
| Tilt Mechanism | Self-locking worm gear with ergonomic hand wheel |
| Agitator Type | Twin-shaft; anchor with nylon scrapers & counter-rotating beater |
| Agitator Speeds | Low 23 / 60 RPM • High 46 / 120 RPM (main/secondary) |
| Approx. Dimensions * | H 42.5" • W 32.3" • D 30.6" |
| Steam Connections | ¾" NPT inlet • ½" NPT condensate outlet |
| Origin | Manufactured in the USA (Waynesboro, GA) |
*Dimensions based on manufacturer’s drawing; allow clearance for tilt radius and service access.
What’s Included
- Legion TWT-30 2/3-jacketed tilting kettle
- Factory-mounted MV twin-shaft agitator
- Control console with mixer & steam controls
- Tri-leg frame with leveling feet
- Comprehensive owner’s manual
Warranty
Backed by Legion’s 12-month parts & labor warranty from date of installation (or 15 months from ship date). Extended coverage available—ask your sales representative.
