Legion TWSWT-80 Wall-Mounted Tilting Kettle with Two-Speed Mixer — 80 gal
Direct Steam • Full Jacket • 304 Stainless Steel • 30 PSIDesigned and built in the USA for the most demanding production kitchens, the Legion TWSWT-80 pairs an 80-gallon direct-steam kettle with an integrated twin-shaft agitator. Its wall-bracket mount frees up valuable floor space, while the self-locking tilt and two-speed mixer guarantee smooth, perfectly blended batches every time.
Key Advantages
- Seamless deep-drawn 304 stainless steel kettle liner for easy sanitation
- 304L full steam jacket rated to 30 PSI for fast, even heat transfer
- Self-locking worm-gear tilt delivers precise, splash-free pouring
- Rugged 304 stainless support arms, seam-welded to jacket
- Two-speed (≈23 & 46 RPM) twin-shaft agitator handles delicate sauces or thick stews*
- Anchor-style main agitator with removable nylon scraper blades that sweep the entire cooking surface
- Counter-rotating secondary beater eliminates dead spots for uniform consistency
- Actuator-assisted lift lets one person raise the mixer bridge with minimal effort
- Balanced, enclosed aluminum mixer bridge & TEFC gear motor for quiet, reliable service
- ASME & NSF compliant; fabricated, assembled and tested in Waynesboro, GA
*RPM values based on standard 15:1 gear-head ratio.
Integrated Twin-Shaft Mixer
- Bayonet-mount agitator & beater remove in seconds for cleaning
- Positive rim-lock keeps the bridge secure during operation & tilt
- Safety interlock prevents high-speed starts
Specification Summary
| Model | TWSWT-80-MV |
|---|---|
| Capacity | 80 gal / 303 L |
| Heating Source | Direct steam, full jacket |
| Operating Pressure | 30 PSI (207 kPa) |
| Construction | 304 SS liner & jacket; SS support arms; reinforced SS gear box |
| Tilt Mechanism | Manual hand-wheel, self-locking worm gear |
| Mounting | Wall-bracket (in-wall carrier optional) |
| Agitator Speeds | Low ≈23 RPM | High ≈46 RPM (main agitator) |
| Steam Connections | ¾″ NPT inlet & outlet |
| Overall Width (A) | 58.8″ / 149 cm |
| Overall Depth (B) | 40.9″ / 104 cm |
| Min. Pour Path (X) | 32.1″ / 82 cm |
| Certifications | ASME, NSF |
Standard Equipment
- Control console with speed selector & start/stop switches
- Balanced tilt handle with ratchet lock
- Steam jacket drain valve
- Stainless steel mixer bridge & shafts
- Set of four nylon scraper blades
- Owner’s/installation manual
Popular Factory Options
- 2″ or 3″ draw-off valve (compression or ball type)
- Single or double fill faucet with 12″ or 18″ swing nozzle
- 48″ flexible spray-rinse hose (vinyl or stainless)
- Automatic water-fill meter
- Lift-off or actuator-assisted one-piece cover
- Prison/security package with lockable lid & reinforced rim
Backed by Legion’s 12-month parts & labor warranty from date of installation. Extended coverage up to three years available at the time of purchase.
