Legion 60-Gallon Direct Steam Tilting Wall-Mount Kettle with Integrated Mixer
Model TWSWT-60 • MV Twin-Shaft AgitatorEngineered for high-output, high-consistency kitchens, the TWSWT-60 couples Legion’s seamless 304 stainless steel kettle with a powerful two-speed mixer. The wall-bracket design frees up floor space, while the self-locking worm-gear tilt provides smooth, controlled pouring—even at a full 60-gallon capacity.
Key performance features
- Full-jacket direct-steam heating for rapid, even temperature distribution.
- Seamless deep-drawn 304 & 304L stainless construction—no interior crevices, no corrosion.
- MV series twin-shaft agitator with anchor blade & counter-rotating beater for uniform mixing of thin or viscous foods.
- Two selectable mixer speeds (High 46 / 120 RPM • Low 23 / 60 RPM) to match delicate sauces or hearty mash.
- Removable nylon scraper blades continuously clean kettle walls to prevent scorching.
- Reinforced stainless gear box and self-locking worm-gear tilt for safe, precise dumping.
- All stainless support arms seam-welded to jacket for unmatched structural integrity.
- NSF & ASME compliant and proudly made in the USA.
Specifications
| Capacity | 60 gal / 227 L |
|---|---|
| Kettle type | Direct steam, full jacketed, tilting |
| Mounting | Wall-bracket (in-wall carrier option) |
| Operating pressure | 30 psi maximum jacket pressure |
| Liner material | Seamless 304 stainless steel |
| Jacket material | 304L stainless steel |
| Tilt mechanism | Self-locking worm-gear with reinforced stainless gear box |
| Mixer type | MV twin-shaft, fixed mount, tilt-out |
| Mixer speeds | High 46 RPM main / 120 RPM secondary • Low 23 RPM main / 60 RPM secondary |
| Agitator design | Anchor-style 304 SS with removable nylon scrapers |
| Steam connections | ¾″ NPT inlet • ½″ NPT outlet |
| Overall width (A) | 32.5″ / 826 mm |
| Overall height (F) | 53.3″ / 1354 mm Mounting height “T” can be field-adjusted. |
| Pour path clearance (X) | 27.1″ / 688 mm |
| Manufactured | Waynesboro, Georgia, USA |
Perfect for
- Soups, stews & chili
- Sauces, gravies & custards
- Pasta, rice or grains
- Mashed potatoes, polenta & other high-viscosity sides
- Confectionery syrups & dessert fillings
Need draw-off valves, flexible spray hoses or automatic water-fill? Ask us about factory-installed options to tailor your kettle to any production requirement.
Product Weight:
785.0 lbFrequently Asked Questions
