Legion TWSWT-40 Direct Steam Tilting Wall-Mount Kettle with Twin-Shaft Mixer
40 gal (151 L) • Full Jacket • 304 Stainless Steel • 30 psiEngineered for high–volume, high-efficiency production, the Legion TWSWT-40 pairs a deep-drawn, wall-mounted kettle with a factory-matched MV twin-shaft mixer. From scratch stocks to sauces, chowders and confectionery syrups, you’ll achieve fast heat-up, even cooking and hands-free agitation—then tilt and pour with total control.
Key advantages
- 40 gallon / 151 liter batch size—perfect for medium-to-large commissaries, restaurants and catering kitchens.
- 304 SS seamless liner & 304L full steam jacket for superior corrosion resistance and sanitation.
- Self-locking worm-gear tilt lets one operator smoothly pour or portion—even at full capacity.
- Factory-installed MV mixer (2-speed) keeps product in constant motion, eliminating hot spots and costly hand-stirring.
- Wall-bracket mounting frees up valuable floor space and simplifies cleaning under the work zone.
- 30 psi operating pressure delivers rapid heat transfer and shorter cook times.
- Made in the USA and built to ASME & NSF standards for long-term reliability.
Kettle construction
- Seamless deep-drawn 304 stainless steel food contact liner—no interior weld seams to trap food soil.
- 304L seamless full jacket rated 30 psi @ 275 °F for efficient steam-to-product heat exchange.
- 304 stainless steel support arms seam-welded to the jacket for rigid, vibration-free service life.
- 304 stainless, reinforced gear box & tilt handle assembly with positive self-locking mechanism.
- Control console with easy-read sight glass (jacket water level) and steam inlet/outlet connections.
Integrated MV twin-shaft mixer
- Two-speed, totally-enclosed gear motor (46/23 rpm main agitator; 120/60 rpm secondary beater).
- Balanced aluminum mixer bridge tilts out of the way for product loading, unload or sanitation.
- Anchor-style main agitator hugs the kettle wall; removable nylon scraper blades wipe the entire surface.
- Counter-rotating 304 SS secondary beater breaks up particulates and improves heat distribution.
- Bayonet-mount shafts allow tool-less removal—run the kettle as a traditional tilt model if desired.
- Safety interlock prevents high-speed starts while the bridge is unlatched.
Technical specifications
| Model | TWSWT-40 (with MV mixer) |
|---|---|
| Capacity | 40 gal / 151 L |
| Operating pressure | 30 psi (full jacket) |
| Steam connections | ¾ in. NPT inlet · ½ in. NPT condensate outlet |
| Mounting style | Wall-bracket, adjustable install height |
| Tilt mechanism | Self-locking worm gear, 200° manual sweep |
| Mixer speeds | Low 23/60 rpm · High 46/120 rpm (agitator/beater) |
| Mixer motor | 1½ HP (high) · ¾ HP (low) totally-enclosed gear motor |
| Interior material | 304 stainless steel, #4 sanitary finish |
| Jacket material | 304L stainless steel, seamless |
| Overall width (A) | 29.5 in / 750 mm |
| Overall height (F) | 49.6 in / 1,260 mm (to rim) |
| Depth (C) | 39.9 in / 1,014 mm |
| Pour path clearance (X) | 25.6 in / 650 mm (minimum) |
| Certifications | ASME, NSF |
| Country of origin | USA |
What’s included
- Legion TWSWT-40 full-jacketed tilting kettle assembly.
- Factory-mounted MV twin-shaft mixer bridge, agitator, beater & scraper blades.
- Wall support brackets & hardware.
- Installation & operation manual.
- Legion 12-month parts & labor warranty (extendable).
Ideal for
- Soups, sauces & gravies
- Pasta and rice cooking
- Custards, puddings & confectionery syrups
- Chili, chowders & stews
- Batch pasteurization
Standard warranty: 12 months from installation (15 months from shipment). Extended coverage available at time of purchase.
