Legion TWSWT-25 Direct Steam Tilting Wall-Mount Kettle with Two-Speed Mixer – 25 Gal.
Full-jacketed 304 SS • 30 psi operating pressure • Made in USAFree up floor space and dial in batch-to-batch consistency with the Legion TWSWT-25. This 25-gallon, full-jacketed kettle mounts securely to the wall, heats with direct steam, tilts effortlessly on a self-locking worm gear, and keeps product moving with a built-in two-speed twin-shaft agitator.
Key benefits
- Seamless deep-drawn 304 stainless steel liner for maximum sanitation and durability.
- 304L full jacket rated to 30 psi for rapid, even heating.
- Self-locking worm-gear tilt—precise, drift-free pouring by a single operator.
- Wall-bracket mounting keeps floors clear for easy cleaning and safer workflow.
- Reinforced 304 SS support arms and control console are seam-welded to the jacket.
- Built in the USA to meet ASME, NSF and other applicable standards.
Integrated two-speed mixer
- Enclosed, balanced aluminum mixer bridge with totally enclosed gear motor.
- Two operating speeds—Low ≈23 RPM (main) / 60 RPM (secondary), High ≈46 RPM / 120 RPM.
- 304 SS anchor agitator hugs the kettle wall; counter-rotating beater keeps the center moving.
- Removable nylon scraper blades prevent scorching and eliminate manual scraping.
- Bayonet mounts allow tool-free removal for cleaning or stationary kettle use.
- Actuator-assisted bridge lift and positive rim-lock clear the agitator for safe tilting.
- Safety interlock prevents high-speed starts unless the mixer is fully engaged.
Technical specifications
| Model | TWSWT-25 with MV Series Mixer |
|---|---|
| Capacity | 25 gal / 95 L |
| Operating pressure | 30 psi (207 kPa) |
| Jacket type | Full, seamless 304L stainless steel |
| Steam connection | ¾" NPT inlet, ½" NPT condensate outlet |
| Tilt mechanism | Hand-crank, self-locking worm gear |
| Mounting | Wall-bracket (in-wall carrier optional) |
| Agitator speeds | Low ≈23 RPM / 60 RPM sec. High ≈46 RPM / 120 RPM sec. |
| Agitator motor | 1 HP (high) / ½ HP (low), totally enclosed |
| Construction | All wetted surfaces 304 SS; exterior stainless with satin finish |
| Compliance | ASME, NSF, UL, ETL and other applicable approvals |
| Country of origin | USA |
What’s included
- Direct-steam kettle body & jacket (30 psi)
- Two-speed twin-shaft mixer with scraper blades
- Control console, hand-tilt wheel & mounting hardware
- ASME relief valve
- Owner’s manual & 12-month parts-and-labor warranty
Popular add-ons (sold separately)
- 12" or 18" swing-nozzle fill faucets (single or dual)
- 48" flexible spray hose (vinyl or stainless)
- 2" or 3" draw-off valves—compression or ball type
- Automatic water fill meter
- Lift-off or actuator-assisted cover
- Basket inserts, pour-lip pan holder & other production accessories
Specifications and design subject to change without notice as Legion Industries pursues continuous product improvement.
Product Weight:
664.0 lbFrequently Asked Questions
