Legion TWSWC-60 Direct Steam Tilting Wall-Mount Kettle with MV Mixer
60 gal | Full-jacketed 304 SS | Made in USACombine rapid direct-steam heating, hands-free mixing and effortless tilting—all while keeping valuable floor space clear. The Legion TWSWC-60 anchors to your kitchen wall, so you can batch-cook 60 gallons of soups, sauces, fillings and more with unmatched speed, consistency and safety.
Key Performance Advantages
- 60 gal (227 L) capacity for high-volume production.
- Seamless deep-drawn 304 SS kettle liner—sanitary, durable and easy to clean.
- 304L full jacket rated 30 psi delivers fast, even heat transfer.
- Self-locking worm-gear tilt mechanism ensures smooth, controlled pouring.
- Wall-console mounting with stainless reinforced support boxes maximizes floor space and simplifies wash-down.
- Rear-facing steam inlet/outlet keeps service connections out of the cook line.
- Factory-installed MV twin-shaft mixer:
- Balanced aluminum bridge with actuator-assisted lift.
- Two-speed, totally enclosed gear motor (High 2 HP / Low 1 HP).
- 304 SS anchor agitator plus counter-rotating beater for complete product movement.
- Removable nylon scraper blades sweep the entire kettle surface.
- Bayonet-mount shafts for fast tool-free removal and cleaning.
- Safety interlock prevents high-speed starts when agitator is raised.
- Built to ASME & NSF standards—quality you can trust.
At-a-Glance Specifications
| Model | TWSWC-60 (with MV Mixer) |
|---|---|
| Capacity | 60 gal / 227 L |
| Operating Pressure | 30 psi (207 kPa) |
| Interior Liner | Seamless 304 stainless steel |
| Jacket Material | 304L stainless steel, full jacket |
| Tilt Mechanism | Self-locking worm gear |
| Mounting | Wall-console with rear plumbing connections |
| Overall Height (A) | 32.5 in (826 mm) |
| Overall Width (B) | 22.3 in (566 mm) |
| Overall Depth (C) | 38.5 in (978 mm) |
| Minimum Pour Path (X) | 32.5 in (826 mm) |
| Steam Inlet / Outlet | ¾" NPT / ½" NPT |
| Mixer Motor | 2 HP (High) / 1 HP (Low), 2-speed |
| Mixer Speeds | Main agitator 46 & 23 rpm; secondary beater 120 & 60 rpm |
| Certifications | ASME, NSF |
| Warranty | 12 months parts & labor |
| Country of Origin | USA |
Popular Factory Options & Accessories
- Single or dual fill faucets with 12" or 18" swing nozzles.
- 48" flexible spray-hose rinse assembly (vinyl or stainless).
- 2" or 3" draw-off valves (compression or ball-type).
- Automatic water-filling meter for precise batching.
- Tri-basket or single-basket inserts for pasta & vegetables.
- Lockable lid & reinforced bar rim for correctional facilities.
Looking for a different capacity, voltage or custom mixer ratio? Reach out—Legion can build a system around your exact menu.
