Legion TWSWC-50 Direct-Steam Tilting Kettle with Twin-Shaft Mixer
50 gal / 189 L • Wall-console mounted • Full-jacket • 30 psiBuilt in the USA for the most demanding production kitchens, the Legion TWSWC-50 combines rock-solid 304 stainless-steel construction with an integrated two-speed agitator system. From silky sauces to hearty chili, this 50-gallon workhorse delivers unbeatable heat transfer, effortless tilting and consistent, hands-free mixing—so your team can produce more with less labor.
Why this kettle earns its keep
- Seamless 304 liner & 304L full jacket—deep-drawn for maximum sanitation and rapid heat-up.
- 30 psi operating pressure handles today’s high-output steam systems.
- Self-locking worm-gear tilt lets one operator pour precise portions with zero back-strain.
- Wall-console mounting saves valuable floor space and keeps plumbing safely at the rear.
- Reinforced stainless support consoles house all steam connections—no external manifolds to install.
- ASME & NSF compliant; fabricated, inspected and pressure tested in the USA.
Factory-mounted MV Mixer
- Twin-shaft design with anchor-style main agitator contoured to scrape the entire kettle wall.
- Counter-rotating secondary beater breaks up particulates for even distribution.
- Two-speed gear motor (High 46 RPM / Low 23 RPM on main agitator) adapts to delicate creams or thick stews.
- Removable nylon scraper blades and bayonet-mount shafts pop off in seconds for cleaning or batch change-over.
- Actuator-assisted lift raises the agitator and mixer bridge clear when you need unobstructed access.
- Built-in safety lock prevents high-speed starts while the agitator is out of position.
Technical specifications
| Capacity | 50 gal / 189 L |
|---|---|
| Operating pressure | 30 psi saturated steam |
| Construction | Seamless 304 SS liner, 304L SS jacket, stainless consoles |
| Jacket type | Full jacket, direct steam |
| Tilt mechanism | Self-locking worm gear, hand wheel |
| Mixer motor | 2 HP, two-speed gear motor (46 / 23 RPM main agitator) |
| Steam inlet / outlet | ¾" NPT (in) / ½" NPT (out) |
| Interior diameter (A) | 29.5 in (750 mm) |
| Interior depth (B) | 21.8 in (554 mm) |
| Overall width (T) | 36.9 in (938 mm) |
| Overall height | 30.5 in (775 mm) to top of consoles |
| Minimum pour clearance (X) | 32.0 in (813 mm) |
| Mounting style | Wall-console, rear-plumbed |
| Certifications | ASME, NSF |
| Origin | Waynesboro, Georgia, USA |
Perfect for
- Soups, chowders & chili
- Custards, puddings & pastry cream
- Sauces, gravies & reductions
- Rice, grains & pasta
- Large-batch sautéing or braising before pressureless steaming
Need faucet kits, draw-off valves or security options? A full range of factory accessories is available—contact us for a tailored quote.
