Legion TWSWC-40MV Steam Kettles
Description
Legion TWSWC-40 Direct Steam Tilting Wall-Mount Kettle with MV Mixer – 40 Gal.
Full-jacketed • 304 Stainless Steel • 30 psi Operating Pressure • Made in USADesigned for high-volume, high-quality production, the Legion TWSWC-40 pairs a 40-gallon deep-drawn kettle with a powerful twin-shaft MV mixer. The result is a wall-mounted cooking system that heats evenly, mixes reliably and tilts effortlessly—freeing your team to deliver perfectly blended soups, sauces, curries, custards and more, batch after batch.
Key Performance Features
- Seamless 304 stainless steel liner and full 304L jacket for rapid, uniform steam heating up to 30 psi.
- Self-locking worm-gear tilt allows smooth, controlled pouring and holds position at any angle.
- MV twin-shaft agitator (2-speed) keeps product in constant motion—no scorching or sediment.
- Anchor-style main agitator with removable nylon scraper blades sweeps entire kettle surface.
- Counter-rotating secondary beater promotes thorough mixing of thick or particulate recipes.
- Actuator-assisted lift raises the mixer bridge clear for easy kettle access and cleaning.
- Reinforced stainless support consoles house rear-connection plumbing for a clean installation.
- Bayonet-mount agitators detach in seconds—convert the kettle for traditional stationary or tilt cooking.
- ASME-code construction; NSF compliant for open-kitchen peace of mind.
At-a-Glance Specifications
| Model | Legion TWSWC-40 w/ MV Mixer |
|---|---|
| Kettle Capacity | 40 gal | 151 L |
| Construction | Seamless 304 SS liner / 304L SS jacket |
| Operating Pressure | 30 psi (full jacket) |
| Tilt Mechanism | Self-locking worm gear, manual hand-tilt |
| Mounting | Wall-console, rear steam connections |
| Mixer Type | Twin-shaft, two-speed (low/high) |
| Mixer Motor | ¾ HP low / 1½ HP high |
| Agitator RPM | 23 RPM (low) / 46 RPM (high) |
| Secondary Beater RPM | 60 RPM (low) / 120 RPM (high) |
| Overall Height | ≈30 ½ in. (with mixer bridge lowered) |
| Minimum Pour Path (X) | 36.9 in. |
Ideal Applications
- Central kitchens & commissaries
- Correctional & healthcare foodservice
- Sauce, gravy & stock production
- High-volume scratch cooking
Included With Your Kettle
- MV mixer assembly with main agitator, secondary beater & nylon scrapers
- Actuator-assisted bridge/agitator lift
- Rear inlet/outlet steam plumbing in console
- ASME nameplate & safety relief valve (30 psi)
- Owner’s manual & 12-month parts and labor warranty
Common Factory Options (contact us)
- Single or dual water fill faucets with 12" or 18" swing nozzles
- 2" or 3" sanitary draw-off valves
- 48" flexible spray hose assemblies
- Automatic water-meter filling system
- Higher operating-pressure jackets
- In-wall carrier for concealed mounting
Need help configuring accessories or verifying clearances? Chat with our equipment specialists or download the full spec sheet from Legion Industries’ resource library.
