Legion 40-Gallon Electric Tilting Kettle with 2-Speed Mixer
Model TWE-40-MV • 24 kW • Made in USABoost production, tighten temperature control and slash clean-up time with Legion’s Insulated Self-Contained Tilting Kettle. Built around a seamless 304 stainless liner and paired with a powerful twin-shaft agitator, the TWE-40-MV delivers 151 litres (40 gal.) of perfectly mixed soups, sauces, stews and more—day in, day out.
Why You’ll Love It
- Fast, even heating – 2/3 jacketed, 24 kW electric elements heat from 150 °F – 260 °F (65 °C – 127 °C) with tight thermostat control.
- Integrated 2-speed mixer – twin-shaft agitator (23 / 46 rpm) with counter-rotating beater keeps high-viscosity recipes uniform and lump-free.
- Ultra-durable construction – deep-drawn 304 stainless liner, 304L jacket and seam-welded outer casing stand up to daily commercial use.
- Safety first – automatic low-water cut-off, pressure relief valve, air eliminator and tilt cut-off protect staff and equipment.
- Energy-saving insulation – full-body thermal blanket holds the heat in, keeping kitchens cooler and utility bills lower.
- Easy, controlled pour-off – self-locking worm-gear tilt with ergonomic handle empties the kettle smoothly, every time.
- Sanitary clean-up – removable nylon scraper blades wipe the kettle walls while mixing; bayonet-mounted agitator lifts away without tools.
Built-In Twin-Shaft Agitator
- Food-grade 304 stainless anchor agitator contoured to kettle wall.
- Counter-rotating secondary beater for complete top-to-bottom circulation.
- Two operating speeds:
- Low: 23 rpm main / 60 rpm secondary (¾ HP)
- High: 46 rpm main / 120 rpm secondary (1½ HP)
- Actuator-assisted bridge lift for effortless access.
- Safety interlock prevents high-speed starts until bridge is locked.
Technical Specifications
| Capacity | 40 gal. / 151 L |
|---|---|
| Heat Source | Electric, self-contained 2/3 jacket |
| Input Power | 24 kW @ 208–480 V (1Ø or 3Ø) |
| Amperage @240 V | 100 A (1Ø) • 57.7 A (3Ø) |
| Temperature Range | 150 °F – 260 °F (65 °C – 127 °C) |
| Tilt Mechanism | Self-locking worm gear with tilt cut-off switch |
| Construction | 304 SS liner & jacket • 304 SS outer shell, control console & 2″ tubular frame |
| Insulation | Full-body fiberglass blanket between jacket & casing |
| Controls & Gauges | Thermostat, pressure gauge, air eliminator, low-water indicator, relief valve |
| Agitator Motor | 1½ HP (high) / ¾ HP (low) gear motor |
| Floor Mount | Adjustable flanged stainless feet |
| Certifications* | ASME, NSF, UL and other applicable listings |
*Legion equipment is built to comply with agency standards; specific approvals vary by configuration and market.
Perfect For
- Central kitchens & commissaries
- Correctional and institutional feeding
- High-volume restaurants & hotels
- Sauce, stock and gravy production
- Chili, oatmeal, custard & similar viscous foods
Popular Factory Options
- 2″ or 3″ draw-off valve (compression or ball type)
- Automatic water fill meter
- Timer with buzzer or pressure switch
- Hinged or lift-off cover, pour-lip pan holder, basket inserts & more
Product Weight:
