Legion TLGB-60FMV Steam Kettles
Description
Legion Low-Rim™ Gas Tilting Kettle with 2-Speed Mixer – 60 gal
Model TLGB-60F-MV | Self-Contained • Fully Jacketed • Insulated for Safety™Engineered for demanding commercial kitchens, the TLGB-60F brings together 60 gallons of evenly-distributed steam heat and a powerful twin-shaft agitator. Cook, mix and portion from a single, low-profile workstation—while staying safe, efficient and in total control.
Why It Beats a Stock Pot
- 131,400 BTU burner reaches temperature fast and holds it rock-steady.
- Self-contained steam jacket means NO external boiler or steam piping.
- Low-Rim™ design keeps the kettle lip just 25 in. from the floor for safer loading, sampling and cleaning.
- Full 3–14 in. insulation keeps exterior surfaces cool and slashes energy loss.
- Twin-shaft mixer scrapes the entire kettle wall—good-bye scorching and manual stirring.
- Manual, self-locking worm-gear tilt delivers controlled, splash-free pouring.
- Proudly made in Waynesboro, Georgia, USA.
Standard Kettle Features
- Deep-drawn 304 SS food contact liner
- 304L SS, ASME-stamped full steam jacket
- Thermostat-controlled 150 °F – 260 °F range with electronic ignition (120 V)
- Kettle Protection System:
- Pressure relief valve & pressure gauge
- Air eliminator
- Low-water cutoff with indicator light
- Jacket-water fill valve with sight glass
- Seam-welded 304 SS outer casing and control console
- Adjustable flanged feet for permanent, level placement
Integrated MV Twin-Shaft Mixer
- 304 SS anchor-style main agitator contoured to kettle wall
- Counter-rotating beater sweeps center mass for total product movement
- Removable nylon scraper blades for quick sanitation
- Two operating speeds:
- LOW – 23 rpm anchor / 60 rpm beater (¾ HP)
- HIGH – 46 rpm anchor / 120 rpm beater (2 HP)
- Actuator-assisted lift tilts the entire bridge clear for loading, cleaning or tilting
- Safety interlock blocks high-speed starts when agitators are raised
Technical Specifications
| Capacity | 60 gal | 227 L |
|---|---|
| Energy Source | Natural or LP Gas, 131,400 BTU (Natural) / 131,100 BTU (LP) |
| Operating Temp. | 150 °F – 260 °F |
| Steam Jacket | Full, water-sealed, self-contained |
| Construction | 304 SS liner & outer shell, 304L SS jacket |
| Tilt Mechanism | Manual, single-reduction worm gear (self-locking) |
| Mixer Drive | Twin-shaft, 2-speed gear motor (see above) |
| Gas Connection | 1/2 in. NPT | 5–7 in. W.C. Natural | 12–14 in. W.C. LP |
| Electrical | 120 V, 60 Hz, 1 Ø, 1 A (controls & ignition) |
| Overall Width (F) | 57.9 in. (1,471 mm) |
| Overall Depth (L) | 43.4 in. (1,102 mm) |
| Working Height (G) | 47.5 in. (1,207 mm) |
Popular factory options include 2 in. or 3 in. draw-off valves, fill faucets, spray hoses, automatic water meters, quick-disconnect gas hoses, lift-off or actuator-assist lids and more.
