Legion TLGB-60 Steam Kettles
$23,196.43
Unit price
/
Unavailable
Description
Legion TLGB-60 Insulated Self-Contained Tilting Kettle – 60 Gallon
Gas-Fired • 2⁄3-Jacketed • Floor Model • 106,800 BTU (Natural Gas)Engineered for demanding, high-volume kitchens, the TLGB-60 marries the speed of steam with the convenience of a fully self-contained gas system. Its 60-gallon (227 L) capacity, deep-drawn stainless construction and full-body insulation deliver faster batch times, lower energy costs and a cooler kitchen—shift after shift.
Why You’ll Love It
- Heavy-duty 304 stainless steel liner with 304L 2⁄3 jacket for corrosion-proof longevity.
- Insulated for Safety™ – 3 - 14 in of wrap-around insulation keeps exterior surfaces cool and slashes heat loss.
- Precise thermostatic control from 150 °F to 260 °F (66 °C – 127 °C) for perfect soups, sauces and braises.
- Self-contained design—no external boiler or steam supply required.
- One-hand tilting via self-locking, permanently lubricated worm gear for smooth, controlled pour-offs.
- Factory-installed Kettle Protection System with pressure relief, air eliminator & low-water cut-off.
- Electronic ignition, safety pilot and indicator lights for “at-a-glance” status.
- Made in the USA to ASME, NSF and CSA standards.
Technical Specifications
| Capacity | 60 gal / 227 L |
|---|---|
| Heat Source | Natural or Propane Gas, self-contained |
| Input Rating | 106,800 BTU (Natural) • 108,500 BTU (Propane) |
| Jacket | 2⁄3-covered water jacket, 304L stainless |
| Operating Temp. | 150 °F – 260 °F (66 °C – 127 °C) |
| Gas Connection | 3⁄4 in IPS; 5-7" W.C. Natural • 12-14" W.C. LP |
| Electrical | 120 V, 50/60 Hz, 1 Ø, 1 A (208/240 V optional) |
| Construction | Deep-drawn 304 SS liner, seam-welded 304 SS outer casing & frame |
| Overall Width (F) | 56.6 in / 1438 mm |
| Overall Depth (D) | 26.7 in / 678 mm |
| Overall Height (G) | 46.1 in / 1171 mm |
| Origin | Waynesboro, GA USA |
Popular Options & Accessories
- 2 in or 3 in draw-off valve (compression or ball type)
- Single or double fill faucet with 12 in / 18 in swing nozzle
- 48 in flexible spray hose (vinyl or stainless)
- Lift-off or actuator-assisted cover
- Electric timer with buzzer
- Flexible gas hose & ½ in quick-disconnect
- Two-speed mixer/agitator assembly
- Basket, strainer, measuring strip & kettle care kits
Contact our team to configure the TLGB-60 to your specific workflow.
Installation Notice: Gas equipment must be installed and serviced by a qualified technician in accordance with local codes.
A dedicated 120 V electrical connection is required for electronic ignition.
Features & Specs
Features & Specs
Manufacturer
Legion
Width
56.6in
Shipping Weight
720.0lbs
Width
49 - 62 inches
Kettle Jacket
partial jacket
Capacity
50 - 70 gallon
Kettle Liner
304 stainless steel
Specifications
Tilting Kettle, Gas, insulated, self-contained, 60-gallon, 304 stainless steel liner, floor model, 2/3 jacket, 106,759 BTU
