Legion TLGB-40MV Steam Kettles

SKU: TLGB-40MV
$51,105.30
/each
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Legion New Arrivals

Legion TLGB-40 Gas Tilting Kettle with 2-Speed Mixer – 40 gal

Insulated Self-Contained • 2/3 Jacketed • 79,900 BTU (Natural Gas)

Built in the USA for demanding, high-volume kitchens, the Legion TLGB-40 combines a fully jacketed, gas-fired kettle with an integrated twin-shaft agitator. Precise temperature control, continuous scraping and fast, even heat distribution let you produce soups, sauces, fillings and reductions faster—without standing over the pot.

Key Benefits

  • 304 SS liner, jacket, frame & controls for superior hygiene and corrosion resistance.
  • Deep-drawn 2/3 jacket surrounds product with gentle, uniform heat up to 260 °F.
  • “Insulated for Safety™” 3″-14″ full-body insulation keeps the exterior cool and slashes energy loss.
  • 79,900 BTU/h burner with electronic ignition and safety pilot for reliable, fast start-ups.
  • Factory-installed MV mixer:
    • Two-speed gear motor (46 rpm high / 23 rpm low main agitator).
    • 304 SS anchor agitator with removable nylon scraper blades.
    • Counter-rotating secondary beater eliminates hot spots and maintains product consistency.
    • Actuator-assisted bridge lift and positive rim lock for easy kettle access.
  • Self-locking, permanently lubricated worm-gear tilt for smooth, controlled pour-off.
  • Thermostatic dial (150 °F–260 °F) plus low-water cutoff, pressure relief valve, sight glass and gauge protect every batch.
  • NSF, UL, CSA & ASME compliant.

Built-In Safety & Protection

  • Kettle Protection System with air eliminator and automatic low-water indicator.
  • Pressure vessel stamped to ASME code.
  • Cool-touch, seam-welded stainless outer casing.
  • Adjustable flanged feet for secure floor mounting.

Technical Specifications

Capacity 40 gal / 151 L
Heat Source Natural Gas 79,900 BTU/h (Propane 83,100 BTU/h optional)
Operating Temp. 150 °F – 260 °F (65 °C – 127 °C)
Jacket 2/3 steam jacket, 304L SS, 30 psi max
Insulation 3″-14″ full-body fiberglass
Mixer Drive 2-speed gear motor (46 rpm / 23 rpm main agitator)
Gas Connection ¾″ NPT (IPS)
Gas Pressure Natural 5-7″ W.C. • Propane 12-14″ W.C.
Factory outlet setting: 3.5″ W.C. (Nat) / 9.0″ W.C. (LP)
Electrical 120 V, 1 ph, 50/60 Hz, 1 A — powers ignition & controls
(Mixer voltage selectable 115/208/230/460 V)
Overall Dimensions* W 51.1″ × D 26.2″ × H 42.5″ (to rim)
See drawing for full clearance details.

*Dimensions taken from manufacturer’s drawing with optional 3″ draw-off valve.

What’s Included

  • TLGB-40 insulated tilting kettle with integrated MV mixer
  • Mounted control console with thermostat & indicator lights
  • Pressure gauge, relief valve, air eliminator & sight glass
  • 6′ factory-wired power cord (NEMA plug)
  • Owner’s manual & start-up checklist

Popular Factory Options

  • 2″ or 3″ sanitary draw-off valve (ball or compression)
  • Automatic water-fill meter
  • Electric batch timer with buzzer
  • Single or dual-fill faucet with 12″/18″ swing nozzle
  • Flexible spray hose assembly
  • Gas quick-disconnect kit & flexible gas hose
  • Basket inserts, perforated disk strainers, measuring strip & more
Installation Required: A licensed professional must connect all gas, electrical and water utilities in accordance with local codes and the manufacturer’s instructions. Adequate floor support is required.

Reduce labor, boost consistency and keep your production line moving—upgrade to the Legion TLGB-40 today.

Product Weight:

995.0 lb
Manufacturer Legion
Shipping Weight 995.0lbs
Base quad-leg
Type tilt
Kettle Jacket partial jacket
Capacity 40 gal
Kettle Liner stainless steel
Specifications Tilting Kettle, Gas, with mixer, insulated, self-contained, 40-gallon, 304 stainless steel liner, floor model, 2/3 jacket, 79,855 BTU
