Legion TLGB-40FMV Steam Kettles

SKU: TLGB-40FMV
$60,876.08
/each
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Legion New Arrivals

Legion Low-Rim™ 40-Gallon Gas Tilting Kettle with 2-Speed Mixer

Model TLGB-40F-MV  |  Full-jacketed • Insulated • Self-contained Floor Model

Built for the demands of high-volume production kitchens, the Legion TLGB-40F pairs a 106,759 BTU gas-fired, fully jacketed kettle with an integrated twin-shaft agitator system. Expect faster batch times, flawless product consistency, and operator-friendly ergonomics— all in a rugged 304 stainless-steel package proudly made in the USA.

Kettle Highlights
  • 40 gal (151 L) deep-drawn, one-piece 304 SS liner for exceptional sanitation
  • 304L SS full jacket (50 psi) delivers gentle, uniform heating—no external boiler required
  • Low-Rim™ design keeps the rim height to just 35.6 in for comfortable loading, stirring & tasting
  • Insulated for Safety™—3 – 14 in of mineral wool keeps heat in the kettle, not the kitchen
  • Thermostatic control 150 °F – 260 °F with jacket-water sight glass & fill port
  • Kettle Protection System: pressure relief valve, air eliminator, pressure gauge, low-water cutoff & indicator light
  • Electronic spark ignition (120 V cord & plug) with safety pilot
  • Self-locking worm-gear tilt and reinforced gearbox for smooth, drip-free pouring
  • Seam-welded 304 SS outer shell, console, tubular frame & adjustable flanged feet
Integrated 2-Speed Mixer
  • Twin-shaft design: anchor-style main agitator & counter-rotating beater
  • Removable nylon scrapers sweep the entire kettle surface for superior heat transfer
  • Two mixing speeds—High 46 rpm / Low 23 rpm (main shaft)
  • Actuator-assisted bridge lift with positive rim lock for rapid tool changes & cleaning
  • Safety interlock prevents high-speed starts when agitators are lifted
  • Bayonet-mount tools allow kettle to be used with or without the mixer head
Specifications
Capacity 40 US gal | 151 L
Liner / Jacket 304 SS liner • 304L SS full jacket
Heat Source Natural gas, 106,759 BTU /hr (propane available)
Temperature Range 150 °F – 260 °F (65 °C – 127 °C)
Ignition / Electrical Electronic spark, 120 V, 1 ph, 1 A
Gas Connection ¾″ IPS, 5 – 7″ W.C. inlet • 3.5″ W.C. outlet (factory set)
Mixer Drive 2-speed gear motor • 46/23 rpm main • 120/60 rpm secondary
Overall Dimensions 56.6 W × 26.7 D × 46.1 H in (F × D × G)
Rim Height 35.6 in
Tilt Clearance 17.1 in with 3″ valve
Certifications ASME • NSF • CSA • ETL Sanitation
What’s Included
  • TLGB-40F gas tilting kettle (pre-charged jacket water)
  • Factory-installed twin-shaft MV mixer assembly
  • 6 ft power cord with plug
  • Operator’s manual & warranty documentation
NOTE: A ¾″ gas shut-off valve, potable water for jacket fill, and floor drain are required for installation. Optional accessories—2″/3″ draw-off valves, fill faucets, automatic water meters and more—are available on request.

Made in Waynesboro, GA USA  •  Legion Industries reserves the right to modify specifications without notice.

Product Weight:

1090.0 lb
Manufacturer Legion
Shipping Weight 1090.0lbs
Type tilt
Base quad-leg
Capacity 40 gal
Kettle Jacket full jacket
Kettle Liner stainless steel
Specifications Low-Rim Tilting Kettle, Gas, with mixer, insulated, self-contained, 40-gallon, 304 stainless steel liner, floor model, full jacket, 106,759 BTU
