Legion TLGB-20FMV Steam Kettles
Description
Legion LOW-RIM™ 20-Gallon Gas Tilting Kettle with 2-Speed Mixer
Model TLGB-20F-MV • Insulated Self-Contained • Made in USAEngineered for high-volume, high-precision cooking, the 20-gallon Legion TLGB-20F pairs a full-jacketed, gas-fired kettle with a factory-mounted, twin-shaft agitator. From scratch sauces to delicate custards, the LOW-RIM™ design puts every operator within easy reach while delivering the power, safety and consistency modern kitchens demand.
Why You’ll Love It
- Deep-drawn 304 stainless steel kettle liner resists pitting and corrosion.
- Full 304L stainless steel jacket surrounds the kettle for even, gentle heat transfer.
- Built-in Kettle Protection System with pressure relief, air eliminator & low-water cut-off.
- Thermostat-controlled temperature range: 150 °F – 260 °F (65 °C – 127 °C).
- Factory-installed, 2-speed twin-shaft agitator:
- Anchor-style main agitator hugs the kettle wall.
- Nylon scraper blades prevent product burn-on.
- Counter-rotating beater keeps ingredients homogenous.
- LOW-RIM™ profile (16.2 in./412 mm rim height) for safer, ergonomic access.
- Self-locking worm gear tilt mechanism—smooth, precise pouring every time.
- 3 in.-14 in. thick mineral fiber insulation keeps heat in and skin-temperature out.
- Electronic ignition, 120 V cord & plug included—no external boiler required.
- Adjustable flanged feet bolt to the floor for rock-solid stability.
Performance Specs
| Capacity | 20 gal (76 L) |
|---|---|
| Total BTU Input | 66,700 BTU /hr (Natural) | 67,800 BTU /hr (LP) |
| Gas Connection | ½ in. NPT, rear right |
| Gas Pressure (factory set) | 3.5 in. W.C. (Nat) | 9.0 in. W.C. (LP) |
| Electrical | 120 V, 1 Ph, 50/60 Hz, 1 A (electronic ignition & mixer lift) |
| Agitator Motor | 1 HP, 2-speed (Low 23 RPM / High 46 RPM) |
| Rim Height | 16.2 in. (412 mm) |
| Overall Width (F) | 47.7 in. (1 212 mm) |
| Overall Depth (D) | 23.8 in. (604 mm) |
| Overall Height (G) | 39.0 in. (991 mm) |
| Shipping Weight | ≈ 680 lb (308 kg) |
| Certifications | ASME, NSF, CSA, UL listed components |
Built-In Safety Suite
- Automatic low-water cut-off & indicator light
- Pressure relief valve & calibrated gauge
- Safety pilot with electronic ignition—no open flame standing pilot
- Anti-restart lockout prevents high-speed mixer starts when bridge is raised
Popular Factory Options
- 2 in. or 3 in. draw-off valve (compression or ball-type fitting)
- Single or double fill faucet with 12 in./18 in. swing nozzle
- 48 in. flexible spray hose (vinyl or stainless)
- Actuator-assisted lift-off cover
- Electric timer with buzzer for batch repeatability
Contact us for custom voltages, quick-disconnect gas hoses, security packages and other accessories.
Legion’s policy of continuous improvement may result in specification changes without notice. Always consult the latest Legion Industries documentation before ordering.
