Legion SKL9-9 Skittle Braising Pans & Tilt Skillets
Description
Legion Skittle® SKL9-9 Multi-Function Cooker
Steam • Grill • Boil • Fry • RoastReplace multiple pieces of equipment with one powerhouse. The Skittle® SKL9-9 combines a 40-gallon kettle, flat griddle, fryer, steamer and roasting oven in a compact, 10° tilting pan that lets you cook, finish and serve from the same station—all while saving space, energy and labor.
Key Advantages
- 9-in-1 versatility – holds nine 12"×20"×2.5" hotel pans or nine full-size cooking baskets.
- 17.7 kW electric heating with an adjustable thermostat (175 °F – 400 °F) and built-in high-limit safety.
- 10° manual tilt and 31" working height for ergonomic pouring, scraping and cleaning.
- Patented insulated Capsule Lid™ with actuator-assisted, variable-position opening and adjustable steam vent.
- 304 stainless steel food zone, seamless pan body and tubular frame—built in the USA for decades of heavy-duty service.
- Factory-installed 1 ½" compression draw-off valve with tapered access rim and integrated food-pan holder.
- Single ball-valve faucet and 48" stainless flexible spray hose speed clean-up and filling.
- Leg-mounted design with adjustable flanged feet for easy bolt-down and code compliance.
Capacities & Performance
| Pan / Basket Capacity | (9) 12"×20"×2.5" pans | (9) cooking baskets |
|---|---|
| Cooking Surface Area | 1,029 in² flat griddle / grill |
| Kettle Volume | 40.1 gal (152 L) |
| Frying Oil Capacity | 105 lb (47.6 kg) |
| Usable Oven Volume | 10.6 ft³ (0.30 m³) |
| Tilt Angle | 10° front discharge |
Electrical & Utilities
| Power Rating | 17.7 kW electric |
|---|---|
| Standard Voltage | 240 V, 3Φ (other voltages available) |
| Full-Load Amps @ 240 V 3Φ | 42.7 A |
| Water Connection | Single ball-valve fill with 48" spray hose |
| Drain Connection | 1 ½" compression draw-off (2" & 3" optional) |
Included with Your Skittle®
- Cassette rack system for nine 12"×20" pans
- (9) perforated stainless cooking/steaming baskets
- Patented Capsule Lid™ with condensate containment “L” channel
- 48" stainless spray hose & single ball valve faucet
- Adjustable flanged legs and mounting hardware
- Owner’s manual and Legion 12-month parts & labor warranty
Popular Accessories (sold separately)
- Automatic water-fill meter
- Perforated or solid food pans (2½", 4", 6" depths)
- Draw-off strainer, drain hose or spout
- #10 can holder, fry scoop, flat-bottom scoop
- Electric timer with buzzer
- Lockable control cover & security fasteners
Need a different voltage, phase or draw-off size? Legion builds every Skittle® to order—contact us for custom configurations.
Made in Waynesboro, GA | Complies with NSF, UL & ASME standards | U.S. Patent 5,553,531 & 5,964,145
