Legion SKL9-7 Skittle Braising Pans & Tilt Skillets
Description
Legion Skittle® Multi-Function Cooker – Model SKL9-7
Steam • Grill • Boil • Fry • Roast — all in one 10° tilting electric skittleConsolidate bulky kettles, skillets, griddles and fryers into one compact workhorse. Built in the USA from seam-welded 304 stainless steel and Insulated for Safety™, the Skittle SKL9-7 delivers unmatched versatility for high-volume kitchens that demand speed, consistency and easy clean-up.
Key Advantages
- True multi-mode cooking – effortlessly switch between steaming, grilling, boiling, shallow-frying or roasting.
- 10° manual tilt lets you plate, pour or drain without lifting heavy pans.
- Patented Capsule Lid with actuator-assisted opening, adjustable steam vent and condensate containment.
- 175 – 400 °F adjustable thermostat with high-limit safety cut-off.
- Full 304 stainless food contact zone plus 1 ½ in. compression draw-off for effortless product transfer.
- Factory-installed cassette racks hold up to nine 12 × 20 × 2.5 in. hotel pans.
- Insulated sides & bottom slash heat loss and keep the exterior cool to the touch.
- 48 in. stainless spray hose speeds rinsing and daily clean-up.
- Adjustable flanged feet for rock-solid, code-compliant floor mounting.
- NSF, UL & ASME compliant — welded, finished and tested in Waynesboro, GA.
Capacities at a Glance
| Insert pans | 9 × 12 in. × 20 in. × 2.5 in. |
|---|---|
| Cooking / steaming baskets | 9 (11 in. × 20.5 in. × 5 in.) |
| Griddle / skillet area | 1,029 in² |
| Liquid kettle capacity | 31.2 gal (118 L) |
| Frying oil volume | 105 lb (47.6 kg) |
| Oven / holding volume | 9.4 ft³ (0.27 m³) |
Technical Specifications
| Heat source | Electric, 17.7 kW |
|---|---|
| Standard voltage | 240 V, 3 Ø (other voltages available: 208 / 380 / 415 / 440 / 480 V; single-phase on request) |
| Amperage @ 240 V 3 Ø | 42.7 A |
| Draw-off valve | 1 ½ in. compression type, stainless |
| Working height | 31 in. (787 mm) |
| Tilt range | 10° forward |
| Construction | Seam-welded 304 SS pan, lid, frame & component enclosure |
| Country of origin | USA |
Standard Equipment Supplied
- Skittle SKL9-7 base unit with integrated 10° tilt mechanism
- Patented Capsule Lid with safety handle & variable positioning
- Cassette racks for nine hotel pans (pans & baskets sold separately)
- 1 ½ in. stainless compression draw-off valve with food-pan holder
- 48 in. stainless flexible spray hose & single ball valve
- Installation & operation manual
Popular Accessories (sold separately)
- Perforated or solid 12 × 20 in. food pans – 2.5, 4 or 6 in. deep
- Perforated steaming baskets
- Draw-off strainers, spouts & drain hoses
- Automatic water fill meter & dual-fill faucet kits
- Lockable control cover for correctional facilities
- Electric timer with audible buzzer
Need a custom voltage, drain size or accessory package? Our product specialists will configure a Skittle to match your exact menu and production goals.
