Legion SKL9-11 Skittle Braising Pans & Tilt Skillets
Description
Legion Skittle® Model SKL9-11 Multi-Function Cooker
9-Pan • 49 gal Kettle • 17.7 kW Electric • 10° TiltTake on high-volume steaming, grilling, boiling, frying and roasting with a single USA-built workhorse. The Skittle® SKL9-11 delivers enormous capacity, pinpoint temperature control and industry-leading safety in an ultra-durable 304 stainless package.
Key advantages
- Handles (9) full-size 12" × 20" × 2.5" pans or baskets—over 1,000 in² of cooking surface.
- 49 gallon kettle / 105 lb oil volume for batch after batch of soups, sauces or fried favourites.
- 10° forward tilt keeps the 31" working height ergonomic while speeding pan-out and cleanup.
- Capsule Lid™ with actuator-assist, adjustable steam vent and “L”-channel condensate control.
- 175 °F–400 °F thermostat plus independent high-limit safety shuts heat down instantly if needed.
- 1 ½" compression draw-off valve and 48" stainless spray hose simplify draining and rinsing.
- Fully insulated pan, sides & bottom protect staff and cut energy loss—Insulated for Safety™.
- Leg-mounted, seam-welded tubular frame with adjustable flanged feet for secure floor anchoring.
- 17.7 kW heavy-duty elements; 240 V 3-phase standard (208/380/415/440/480 V options).
- NSF, UL & ASME compliant—manufactured and supported in Waynesboro, Georgia.
Technical specifications
| Model | SKL9-11 (leg-mounted, low-lid profile) |
|---|---|
| Functions | Steam • Grill • Boil • Fry • Roast • Sauté • Re-thermalise |
| Pan capacity | (9) 12" × 20" × 2.5" hotel pans (cassette racks included) |
| Basket capacity | (9) 11" × 20 ½" × 5" perforated baskets |
| Cooking area | 1,029 in² |
| Kettle volume | 49.0 gal / 185 L |
| Frying oil | 105 lb / 47.6 kg |
| Tilt angle | 10° manual |
| Thermostat range | 175 °F – 400 °F (79 °C – 204 °C) |
| Heating power | 17.7 kW |
| Electrical (standard) | 240 V, 3-phase, 42.7 A per leg |
| Alternative voltages | 208 / 380 / 415 / 440 / 480 V (field selectable) |
| Draw-off valve | 1 ½" compression (2" & 3" options) |
| Construction | 304 stainless food zone, lid, enclosure & frame; seam-welded & polished |
| Overall dimensions* | 41" W × 47" D × 59" H (lid closed) |
| Warranty | 12-month parts & labour (extended plans available) |
*Dimensions shown with 1 ½" draw-off valve; larger valves alter width slightly.
What’s in the box
- (9) Cassette racks for full-size pans
- 48" stainless flexible spray hose assembly
- Adjustable flanged feet & mounting hardware
- User, installation & maintenance manual
Popular add-ons
- Automatic water-fill meter
- Perforated or solid hotel pans (2½", 4", 6" depths)
- Draw-off strainers, drain hoses & spouts
- Flat or fry scoops, #10 can holder
- Lockable control cover & security fasteners
- Electric timer with buzzer
Need a custom voltage, larger draw-off or knock-down shipping? Reach out and we’ll configure a Skittle® to fit your kitchen perfectly.
