Legion SKL6-9 Skittle Braising Pans & Tilt Skillets
Description
Skittle® SKL6-9 Multi-Function Cooker
Steam • Grill • Boil • Fry • Roast — 6-Pan / 27.4 gal CapacityBuilt in the USA by Legion, the Skittle® SKL6-9 is a true one-station powerhouse for high-volume kitchens. Its insulated, 10° tilting pan and 11.8 kW electric heating let you switch effortlessly between wet and dry cooking methods—so you can blanch vegetables at 8 a.m., deep-fry at noon, and braise overnight without changing equipment.
Highlights
- All-in-one versatility: steam, grill, boil, fry, roast or hold in a single vessel.
- Holds 6 × GN 1/1 (12" × 20" × 2.5") pans or 6 full-size cooking baskets (both included).
- 27.4 gal / 70 lb oil kettle handles big-batch production with ease.
- Ergonomic 10° manual tilt with 31" working height for safe product unloading.
- Seam-welded 304 stainless pan with full side & bottom insulation for energy savings.
- Patented capsule lid—actuator assisted, multi-position, with adjustable steam vent and condensate containment.
- Precision thermostat 175 °F – 400 °F plus independent high-limit safety cutoff.
- 1 ½" compression draw-off valve with built-in under-pan holder for mess-free portioning.
- Factory-installed 48" flexible spray hose & single ball-valve fill for rapid clean-up.
- 304 stainless, leg-mounted frame with adjustable flanged feet—bolt it down and go.
- NSF, UL & ASME compliant; Insulated for Safety™ construction reduces radiant heat in the cookline.
Technical Specs
| Model | Skittle® SKL6-9 |
|---|---|
| Cooking modes | Steam, grill, boil, fry, roast, braise, hold |
| Pan capacity | 6 × 12" × 20" × 2.5" pans (included) |
| Basket capacity | 6 stainless cooking/steaming baskets (included) |
| Kettle / oil volume | 27.4 gal (103.7 L) / 70 lb oil |
| Cooking surface area | 703 in² |
| Heating power | 11.8 kW electric |
| Standard voltage | 240 V, 3-phase (other voltages & single-phase available) |
| Current draw @ 240 V Δ | 28.4 A per leg |
| Temperature range | 175 °F – 400 °F (79 °C – 204 °C) |
| Draw-off valve | 1 ½" compression (2" & 3" optional) |
| Overall footprint (W × D × H) | 28" W × 34" D × 41.3" H* |
| Pan depth | 9" |
*Dimensions shown with standard 1 ½" draw-off. Contact us for alternate valve sizing.
Popular Add-Ons (sold separately)
- Perforated or solid GN pans — 2.5", 4" or 6" deep
- Extra steaming/frying baskets
- Automatic water-fill meter
- Lockable control cover for correctional facilities
- Skittle care kit, fry scoop & flat-bottom scoop
