Legion SKL3-9 Skittle Braising Pans & Tilt Skillets
Description
Legion Skittle® SKL3-9 Multi-Function Cooker
Steam • Grill • Boil • Fry • Roast – one compact powerhouseBuilt for high-volume, high-versatility kitchens, the USA-made Skittle® SKL3-9 replaces a steamer, fryer, kettle, griddle and roasting oven in a single, fully-insulated 304 stainless cabinet. From flash-frying chicken to gently steaming veggies, you’ll turn out consistent results while saving space, labor and energy.
Why chefs love the Skittle®
- Five cooking modes in one appliance – no need for multiple dedicated stations.
- 10° fixed forward tilt keeps liquids pooled up front for faster draining and safer scooping.
- 13.7-gal kettle / 35-lb oil capacity supports large batch production without frequent refills.
- Seam-welded & insulated 304 stainless pan, sides and bottom stay cooler to the touch and cut heat loss.
- Patented actuator-assisted Capsule Lid with adjustable steam vent reduces splatter and energy use.
- Accurate thermostat (175 °F–400 °F) with independent high-limit safety protects against overheating.
- 1½″ stainless compression draw-off valve plus 48″ spray hose for mess-free transfer and cleanup.
- (3) perforated baskets & (3) 12″×20″ pans slot into the built-in cassette rack for batch cooking.
- Heavy-duty, seam-welded tubular frame with adjustable flanged feet bolts securely to the floor.
- All-electric 5.9 kW element – connect to 208-480 V, 1 Ø or 3 Ø (240 V 3 Ø factory standard).
At-a-glance specifications
| Model | SKL3-9 |
|---|---|
| Cooking capacity | 13.7 gal (liquid) / 35 lb (oil) |
| Pans supplied | (3) 12″ × 20″ × 2.5″ stainless food pans |
| Cooking baskets | (3) stainless perforated baskets |
| Griddle/kettle area | 351 in² |
| Tilt angle | 10° forward |
| Thermostat range | 175 °F – 400 °F |
| Heating power | 5.9 kW electric |
| Electrical | 208–480 V, 1 Ø or 3 Ø (240 V 3 Ø 14.2 A standard) |
| Draw-off valve | 1½″ stainless compression |
| Working height | 31″ to pan rim |
| Construction | Seam-welded & insulated 304 stainless steel |
| Certifications | NSF, UL, ASME |
| Country of origin | USA |
What’s in the box
- (3) 12″×20″×2.5″ stainless food pans
- (3) 11″×20.5″×5″ perforated cooking/steaming baskets
- 1½″ compression draw-off valve with 48″ stainless spray hose
- Factory-mounted cassette rack for pans & baskets
- Comprehensive operator’s manual
Looking for a different capacity or voltage? Explore the complete Skittle® line, or contact us for a custom configuration.
