Legion SKL3-5 Skittle Braising Pans & Tilt Skillets
Description
Skittle® Multi-Function Cooker – Model SKL3-5
Steam • Grill • Boil • Fry • Roast – all in one 5.9 kW stationReplace multiple pieces of equipment with one rugged, USA-made workhorse. The Legion Skittle® SKL3-5 tilts, drains and cleans in seconds while delivering restaurant-quality results across five cooking methods in the footprint of a single fryer.
Key Benefits
- True multi-function performance: steam, grill, boil, fry or roast without changing stations.
- 3× full-size hotel pan capacity (12" × 20" × 2.5") plus 2 perforated cooking baskets included.
- 7.6 gal kettle / 35 lb oil or stock capacity handles small-batch to banquet volumes.
- 10° manual tilt makes draining, plating and cleaning fast & safe.
- Patented low-profile Capsule Lid:
- Actuator-assisted variable positioning
- Insulated top & sides for energy savings
- Adjustable steam vent + “L”-shaped condensate baffle
- 175 °F – 400 °F adjustable thermostat with independent high-limit safety.
- 1 ½" compression draw-off valve with food-pan holder underneath for mess-free service.
- 304 stainless, seam-welded pan, frame and component enclosure—built to last & NSF compliant.
- Single ball-valve rinse faucet with 48" stainless flexible spray hose speeds clean-up.
- Leg-mounted design with adjustable flanged feet; 31" working height is ergonomic & ADA friendly.
- UL/NSF listed; Insulated for Safety™ to keep surface temps low and operators protected.
Specifications
| Model | SKL3-5 (Leg-Mounted, Low-Profile Lid) |
|---|---|
| Cooking Area | 351 in² pan surface, 5" pan depth, 10° tilt |
| Capacities | (3) 12" × 20" × 2.5" pans • (2) baskets • 7.6 gal / 35 lb oil |
| Power & Heat | Electric, 5.9 kW; 208 V or 240 V, 1 Ø or 3 Ø |
| Amperage @ 240 V | 24.6 A (1 Ø) • 14.2 A per leg (3 Ø-Δ) |
| Temperature Range | 175 °F – 400 °F (adjustable) |
| Draw-Off Valve | 1 ½" compression type, 304 stainless |
| Exterior Dimensions | 14" W × 27.3" D × 36" H (lid closed) |
| Construction | All 304 stainless; insulated pan sides & bottom |
| Agency Listings | NSF, UL, ASME, CSA compliant |
| Warranty | 12-month parts & labor (extendable) |
Included in the Box
- Skittle® SKL3-5 Cooker (leg-mounted, flanged feet)
- (3) 2.5"-deep stainless hotel pans
- (2) perforated stainless cooking/steaming baskets
- 48" stainless spray hose & ball-valve faucet
- User manual & Skittle care kit
Need higher capacity or accessories like automatic water-fill, timers or security options? Contact us—Legion builds every Skittle® to order with a full menu of factory-installed upgrades.
