Legion SK5-7 Skittle Braising Pans & Tilt Skillets
Description
Legion Skittle® Multi-Function Cooker – Model SK5-7
Electric 10° Tilting Cooker | 5-Pan / 10.6 gal / 35 lb | 5.9 kWReplace a line-up of single-purpose appliances with one rugged workhorse. The Skittle® SK5-7 steams, grills, boils, fries, roasts and holds in a fully insulated 304 stainless pan that tilts a full 10° for effortless draining and plating. Made in the USA and engineered for decades of service, it delivers unmatched versatility in just 25 ½" × 20".
Key Advantages
- Six cooking modes in one compact footprint.
- Holds 5 standard 12" × 20" × 2.5" pans or 4 perforated baskets (included).
- 10° manual tilt eliminates heavy lifting and speeds clean-up.
- 175 °F – 400 °F thermostat with high-limit safety cut-off.
- Patented Capsule Lid with adjustable steam vent—opens smoothly and stays cool.
- Insulated for Safety™ sides & bottom reduce energy loss and protect staff.
- 1½" front-mounted compression draw-off valve with pan holder.
- Welded 304 stainless frame with adjustable flanged feet—built to last.
- 48" stainless spray hose makes rinse-down fast and easy.
Technical Specifications
| Model | SK5-7 (Legion ID 5078) |
|---|---|
| Cooking Capacity | 5 × 12" × 20" × 2.5" pans (4) perforated cooking baskets |
| Kettle / Oil Volume | 10.6 gal liquid | 35 lb frying oil |
| Pan Depth | 7" |
| Heat Input | 5.9 kW electric |
| Standard Power | 240 V, 3-phase (other voltages/phases available) |
| Current Draw | 14.2 A per leg @ 240 V 3Ø |
| Temperature Range | 175 °F – 400 °F (adjustable) |
| Tilt Angle | 10° |
| Draw-Off Valve | 1½" compression type |
| Working Height | 31" |
| Overall Footprint (W × D) | 25.5" × 20" |
| Construction | 304 stainless pan & frame, insulated sides & bottom |
| Certifications | NSF, UL, ASME (and other applicable approvals) |
| Country of Origin | Made in USA |
What’s Included
- Cassette racks for 12 × 20 pans
- (4) perforated cooking/steaming baskets
- Patented Capsule Lid with “L” condensate containment
- 48" stainless flexible spray hose & single ball valve
- User & maintenance manual
Popular Options & Accessories
- Automatic water-fill meter
- Solid or perforated 2½", 4" or 6" deep pans
- Draw-off strainer, drain hose, or #10 can holder
- Electric timer with audible buzzer
- Lockable control cover & security fasteners
Need more capacity? Skittle® models are available up to 15 pans and 49 gallons—contact us for details.
