Legion SK10-11 Skittle Braising Pans & Tilt Skillets
Description
Legion Skittle® SK10-11 Multi-Function Cooker
Steam • Grill • Boil • Fry • Roast — 10-pan / 33.5 gal / 70 lb CapacityPurpose-built for high-volume, menu-diverse kitchens, the SK10-11 Skittle® combines the muscle of a tilting kettle, braising pan, steamer and fryer in one compact, fully electric station. Eleven patented design elements—headlined by the insulated Capsule Lid and 304 stainless, seam-welded pan—deliver faster throughput, lower energy cost and unmatched operator safety.
Why you’ll love it
- True all-in-one: steam, grill, boil, shallow-fry or roast in a single 10° tilting pan.
- Huge batch capacity: holds (10) 12 × 20 × 2½″ hotel pans or (8) perforated cooking baskets.
- High-output 11.8 kW heater reaches 400 °F (204 °C) with an adjustable thermostat & high-limit safety.
- Patented Capsule Lid with actuator-assisted opening, adjustable steam vent and “L” condensate containment.
- Insulated for Safety™: cool exterior walls reduce ambient heat and energy loss.
- 1½″ compression draw-off valve plus 48″ stainless flexible spray hose for rapid product transfer and cleanup.
- Leg-mounted tubular stainless frame with adjustable flanged feet—bolts directly to the floor for rock-solid stability.
- Made in the USA; built to NSF, UL, ASME & CSA standards and protected by multiple U.S. patents.
Technical specifications
| Model | SK10-11 (leg-mounted, 10° tilt) |
|---|---|
| Cooking functions | Steam, grill, boil, shallow-fry, roast, hold |
| Usable pan area | 703 in² griddle/frying surface |
| Kettle volume | 33.5 gal | 126.8 L |
| Frying oil capacity | 70 lb | 31.8 kg |
| Insert pans | (10) GN 1/1 (12 × 20 × 2½″) |
| Cooking baskets | (8) 11″ × 20½″ × 5″ perforated baskets included |
| Working height | 31″ (pan, level position) |
| Heat input | 11.8 kW electric |
| Electrical (standard) | 240 V, 3-phase, 28.4 A/leg (208, 380, 415, 440, 480 V & 1-phase available) |
| Thermostat range | 175 °F – 400 °F (79 – 204 °C) |
| Construction | All-welded 304 stainless pan, lid, enclosure & frame |
| Draw-off valve | 1½″ compression type with removable strainer |
| Included hose | 48″ stainless flexible spray/fill hose with ball valve |
| Certifications | NSF, UL, ASME, CSA |
| Country of origin | USA |
Popular options & accessories
- 2″ or 3″ draw-off valve (ball or compression type)
- Automatic water-fill meter
- Electric timer with buzzer
- Perforated or solid 12 × 20 pans (4″ & 6″ depths)
- Lockable control cover for correctional facilities
- Skittle care kit, fry scoop, flat-bottom scoop & #10 can holder
Contact our team for a full list of factory-installed options.
U.S. Patents 5,553,531, 5,964,145 & D371,715. Specifications are subject to change without notice.
