Legion LTWT-80MV Steam Kettles
Description
Legion LTWT-80 Stationary Direct Steam Kettle with MV Mixer – 80 Gallon
Wall-Bracket Mounted | 2/3 Jacketed | 304 Stainless Steel | Made in USAEngineered for high-volume kitchens that refuse to compromise on consistency, the LTWT-80 pairs Legion’s deep-drawn steam kettle body with a powerful twin-shaft agitator. Steam, mix, and serve up to 80 gallons of perfectly heated product—every single batch.
Key features
- 80 gal (303 L) capacity—ideal for soups, sauces, stews & confectionery products
- Seamless 304 stainless steel liner and 2/3 jacket provide even, scorch-free heat transfer
- MV twin-shaft mixer with two-speed gear motor for thorough agitation of heavy or delicate recipes
- Anchor-style main agitator hugs kettle contour; counter-rotating beater and nylon scraper blades keep walls spotless
- Actuator-assisted mixer bridge and domed cover lift effortlessly for full interior access
- 2" 304 SS compression draw-off valve with ¼" perforated disk strainer—fast, clog-free dispensing
- 30 psi operating pressure accelerates heat-up times
- Space-saving wall-bracket mounting; 304 SS support arms are seam-welded to the jacket for rock-solid stability
- ASME code stamped & NSF listed for commercial foodservice
MV mixer highlights
- Balanced aluminum bridge with totally enclosed gear motor
- Two operating speeds: 23 RPM (low) & 46 RPM (high) on main agitator; 60 RPM / 120 RPM on secondary beater
- Bayonet-mount agitators remove in seconds for cleaning or stationary kettle use
- Positive rim-lock and safety interlock prevent high-speed starts when bridge is raised
Technical specifications
| Model | LTWT-80 (with MV mixer) |
|---|---|
| Capacity | 80 gal / 303 L |
| Operating pressure | 30 psi (2.07 bar) |
| Jacket coverage | Two-thirds of kettle body |
| Liner & jacket material | Seamless 304 & 304L stainless steel |
| Draw-off | 2" 304 SS compression valve with ¼" perforated strainer |
| Cover | One-piece domed stainless steel, actuator assisted |
| Mixer motor | 2 HP (high) / 1 HP (low) gear motor, 15 : 1 ratio |
| Inside diameter (A) | 32.5 in / 826 mm |
| Inside depth (B) | 27.6 in / 701 mm |
| Overall width (C) | 42.7 in / 1085 mm |
| Recommended mount height (T) | 21.5 in / 546 mm below bracket top |
| Steam connections | ¾" NPT inlet & 1" NPT return |
Dimensional data taken from Legion engineering drawing Rev 113.
Perfect for
- Central production & commissary kitchens
- Correctional and institutional foodservice
- Sauce, jam, and confectionery processing plants
- Ghost kitchens & high-volume catering operations
Upgrade to the Legion LTWT-80 with integrated mixer and experience faster batch times, unmatched product consistency, and a cleaner, safer workspace—all backed by American craftsmanship.
