Legion  |  SKU: LTWT-60MV

Legion LTWT-60MV Steam Kettles

$39,006.20
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options

Documents
Related Searches

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Legion 60-Gallon Stationary Direct Steam Kettle with 2-Speed Mixer

Model LTWT-60-MV | Wall-Bracket Mounted | Made in USA

Engineered for continuous, high-volume production, the LTWT-60-MV pairs Legion’s legendary 2/3-jacketed steam kettle with a powerful twin-shaft agitator. The result is faster cook times, consistent product quality and lower labor costs—all while freeing up valuable floor space.

Highlights

  • 60 gal / 227 L capacity handles large batches of soups, sauces, fillings and more
  • Direct-steam 2/3 jacket delivers even heating up to 30 psi (ASME-code stamped)
  • Seamless 304 stainless kettle liner & 304L jacket resist pitting, corrosion and flavor carry-over
  • Twin-shaft MV mixer (two-speed gear motor) for thorough agitation and product turnover
  • Anchor-style main agitator with removable nylon scraper blades keeps walls & base clean
  • Counter-rotating secondary beater eliminates dead zones for perfectly uniform results
  • Actuator-assisted bridge & agitator lift for safe, tool-free access to the kettle interior
  • 2" 304 SS compression draw-off valve with ¼" perforated strainer disc for smooth, clog-free draining
  • Wall-mount support arms (304 SS, seam-welded to jacket) maximize floor clearance
  • Spring-assist, one-piece domed stainless cover contains heat and minimizes condensation drip
  • NSF listed; built, tested and shipped from Waynesboro, GA

Why Kitchens Choose Legion

  • Rapid heat-up & recovery slash batch times versus stockpots
  • Continuous scraping prevents scorching, improves yield and simplifies cleanup
  • Hands-free mixing cuts labor and boosts operator safety
  • Wall-hung design keeps the floor clear for carts, drains and easy wash-down

Technical Specifications

Capacity 60 gal (227 L)
Operating Pressure 30 psi (2.1 bar)
Jacket Type 2/3 steam jacket, direct connection
Liner Material Seamless deep-drawn 304 stainless steel
Draw-off Valve 2" compression, 304 SS, with ¼" perforated strainer
Mixer Drive Twin-shaft, two-speed gear motor (≈ 23 / 46 rpm main agitator)
Utilities Steam inlet & return; 115/208/230/460 V electric for mixer (specify)
Mounting Wall-bracket arms, 304 SS seam-welded to jacket
Cover Actuator-assisted, one-piece domed stainless steel
Inside Depth (C) 39.8 in (1 011 mm)
Inside Diameter (A) 29.5 in (749 mm)
Recommended Mount Height (T) 12.0 in (305 mm) – field adjustable
Compliance ASME, NSF, UL (mixer), CSA as applicable
Standard Warranty 12 months parts & labor from install (15 months from ship)

Looking for alternate voltages, automatic water fill, basket inserts or security packages? Contact our team for fast quotes on custom configurations.

Features & Specs

Manufacturer

Legion

Shipping Weight

735.0lbs

Jacket

2/3 jacket

Base

wall mount

Type

stationary

Kettle Liner

stainless steel

Capacity

60 gal

Specifications

Stationary Direct Steam Kettle, with mixer, 60-gallon, 304 stainless steel liner, 2/3 jacket, 2" draw-off valve with perforated 1/4" hole strainer, stainless steel construction, wall mounting stainless steel support arms seam welded to jacket, 30 psi
