Legion LTWT-40MV Steam Kettles
Description
Legion LTWT-40 MV – 40 Gal Stationary Direct Steam Kettle with Twin-Shaft Mixer
2/3 jacket • wall-mounted • 30 psi operating pressureBuilt for the busiest production kitchens, the LTWT-40 MV fuses Legion’s seamless 40-gallon direct-steam kettle with a powerful twin-shaft agitator. The result is rapid, even heating and hands-free mixing in a compact wall-mounted package that maximizes floor space while delivering rock-solid 304 stainless-steel durability.
Why You’ll Love It
- Seamless 304 stainless liner – deep-drawn in one piece to eliminate pitting and hard-to-clean weld seams.
- 2/3 steam jacket surrounds the sidewalls for faster heat-up and superior temperature consistency.
- Integrated MV twin-shaft mixer (2-speed) keeps high-viscosity foods moving and prevents scorching.
- Wall-mount stainless support arms are seam-welded to the jacket for unmatched stability and a clutter-free floor.
- 2″ compression draw-off valve with ¼″ perforated disk strainer for fast, clog-free portioning.
- Actuator-assisted one-piece domed cover lifts effortlessly, sealing in heat when closed.
- 30 psi operating pressure handles higher steam supply lines for accelerated batch times.
- All wetted parts are 304/304L stainless steel—NSF listed and easy to sanitize.
- Made in the USA and designed for ASME compliance.
Twin-Shaft Mixer Advantages
- Balanced aluminum bridge with totally-enclosed gear motor protects components from steam and spills.
- Anchor-style main agitator contours the kettle wall while removable nylon blades continuously scrape the surface.
- Counter-rotating secondary beater breaks up lumps and drives uniform product circulation.
- Quick-release bayonet mounts let you remove both agitators without tools for thorough cleaning or non-mixing applications.
- Safety lockout prevents high-speed starts when the bridge is raised.
Technical Specifications
| Capacity | 40 gal / 151 L |
|---|---|
| Operating Pressure | 30 psi (207 kPa) |
| Kettle Construction | Seamless 304 SS liner, 304L 2/3 jacket |
| Mounting | Wall-bracket, stainless arms seam-welded to jacket |
| Cover | One-piece domed, actuator-assisted |
| Draw-off | 2″ compression valve with ¼″ hole perforated strainer |
| Mixer Type | Twin-shaft, tilt-out bridge |
| Mixer Motor | Two-speed – High 1.5 HP / Low 0.75 HP |
| Agitator RPM | High 46 RPM • Low 23 RPM |
| Secondary Beater RPM | High 120 RPM • Low 60 RPM |
| Inside Diameter (A) | 25.5 in (648 mm) |
| Inside Depth (B) | 22.3 in (567 mm) |
Perfect For
- Soups, sauces & stews
- Custards, puddings & confectionery fillings
- Chili, meat or bean products
- High-viscosity items like mashed potatoes or polenta
Legion kettles are engineered to meet or exceed applicable ASME & NSF standards and ship with a 12-month parts & labor warranty.
