Legion LTWT-30 Stationary Direct Steam Kettle with Mixer – 30 gal
Wall-Bracket Mounted | 2/3-Jacketed | 30 psi Operating PressureEngineered for demanding production kitchens, the 30-gallon Legion LTWT-30 marries the rock-solid reliability of a 2/3 jacketed direct-steam kettle with the productivity boost of an integrated twin-shaft mixer. From silky sauces to thick chowders, you’ll achieve faster heat-up, uniform results and worry-free clean-up—all in one wall-mounted workhorse that maximizes floor space.
Why you’ll love the LTWT-30
- Deep-drawn seamless 304 stainless steel liner—no interior welds to trap food soil.
- 304L stainless 2/3 steam jacket delivers rapid, even heating over two-thirds of the kettle body.
- Factory-installed Mixer/Agitator (twin-shaft, 2-speed) keeps high-viscosity recipes moving and eliminates scorching.
- 2 in. compression draw-off valve with ¼ in. perforated disk strainer for clog-free portioning and stock recovery.
- Heavy-duty stainless support arms seam-welded to the jacket for secure wall mounting—frees up valuable floor area.
- 30 psi operating pressure certified to ASME standards; ideal for most institutional low-pressure steam systems.
- Made in the USA with NSF-listed materials for long service life and easy inspection approvals.
Integrated MV Mixer Highlights
- Enclosed, balanced aluminum bridge with totally-enclosed gear motor.
- Anchor-style main agitator (304 SS) contours the kettle wall; removable nylon scraper blades sweep the entire surface.
- Counter-rotating secondary beater breaks up particulates for superior product homogeneity.
- Bayonet mounting allows both agitators to be removed in seconds for cleaning or when a still kettle is desired.
- Two operating speeds: High — 46 RPM main / 120 RPM secondary (1 HP) | Low — 23 RPM main / 60 RPM secondary (½ HP).
- Actuator-assisted bridge lift with positive rim lock and safety interlock prevents high-speed start-ups.
Technical Specifications
| Capacity | 30 gal / 114 L |
|---|---|
| Steam Jacket | 2/3 coverage, 304L SS, 30 psi max. |
| Liner (Interior) | Seamless deep-drawn 304 SS |
| Draw-off Valve | 2 in. compression type, 304 SS, with ¼ in. perforated disk strainer |
| Mounting | Wall-bracket (stainless arms welded to jacket) |
| Inside Diameter × Depth | 23.0 in. × 20.3 in. (approx.) |
| Overall Height (rim to floor) | ≈ 61.6 in. (mounting height adjustable) |
| Mixer Motor | Totally enclosed, 2-speed, 1 HP / ½ HP (high / low) |
| Certifications | ASME, NSF (components) |
| Origin | Made in the USA |
Requires connection to an external 30 psi (max) low-pressure steam supply and a structurally rated wall surface. Steam inlet/return fittings are ¾ in. NPT.
Product Weight:
590.0 lbFrequently Asked Questions
