Legion LTWT-20MV Steam Kettles
Description
Legion LTWT-20 Direct-Steam Kettle with MV Twin-Shaft Mixer – 20 Gal
Wall-Bracket Mounted | 2/3 Jacket | 304 Stainless | 30 psiFree up floor space and speed up batch production with Legion’s 20-gallon LTWT-20. The seamless, 2/3-jacketed kettle heats evenly with direct steam while a factory-installed, two-speed MV agitator keeps every portion perfectly blended. Built from 100 % 304 stainless steel and proudly made in the USA, this wall-mounted workhorse is ready for high-volume soups, sauces, fillings and more.
Why You’ll Love It
- Even, rapid heating – 2/3-jacketed 304L shell rated at 30 psi distributes steam uniformly for faster cook times and reduced scorching.
- No-tool cleaning – Seamless deep-drawn 304 interior, bayonet-mounted agitators and removable nylon scraper blades rinse clean in seconds.
- Wall-mount design – Heavy-duty 304 support arms are seam-welded to the jacket, keeping floors clear and sanitation simple.
- Smooth product transfer – 2″ stainless compression draw-off valve with ¼″ perforated strainer handles everything from thin broths to chunky chowders.
- Made in the USA – ASME & NSF compliant construction backed by Legion’s 1-year parts & labor warranty.
Integrated MV Agitator Advantages
- Twin-shaft, two-speed gear motor (23/60 rpm low • 46/120 rpm high) adapts to delicate or high-viscosity recipes.
- 304 SS anchor-style main agitator hugs the kettle contour for complete side-wall mixing.
- Counter-rotating 304 SS beater breaks up particulates for unmatched product consistency.
- Removable nylon scraper blades continuously clean the heating surface, preventing burn-on.
- Actuator-assisted lift tilts the bridge clear for loading, cleaning or use of the kettle without mixing.
- Safety interlock prevents high-speed starts and secures the bridge with a quick-acting rim lock.
Technical Specifications
| Model | LTWT-20 (with MV Mixer) |
|---|---|
| Capacity | 20 gal | 76 L |
| Liner Material | Seamless 304 stainless steel, deep-drawn |
| Jacket | 304L stainless, 2/3 coverage, 30 psi design pressure |
| Mounting | Stationary wall-bracket, 304 SS arms seam-welded to jacket |
| Draw-off Valve | 2″ 304 SS compression type with ¼″ perforated strainer disk |
| Agitator System | MV twin-shaft, two-speed (23/60 & 46/120 rpm), 304 SS with nylon scrapers |
| Steam Supply | Direct steam (customer-supplied) – 30 psi maximum |
| Certifications | ASME, NSF |
| Origin | Made in USA |
| Warranty | 12 months parts & labor from installation |
Popular Options & Accessories
- Actuator-assisted domed cover (one-piece or two-piece hinged)
- Single or double fill faucet with 12″/18″ swing nozzle
- 48″ stainless or vinyl spray hose assembly
- Automatic water-fill meter
- Tri-basket or single basket inserts, nylon bag assemblies
- Higher-pressure jacket, air eliminator or pressure-reducing valves
Accessories shown in photos are sold separately. Contact us for configuration assistance.
