Legion 80-Gallon Stationary Direct Steam Kettle w/ Integrated Mixer
2/3-jacketed • Wall-console mounted • 30 psi operating pressureEngineered for high-volume, high-precision production, this 80-gallon Legion direct steam kettle combines rugged 304 stainless-steel construction with a powerful twin-shaft agitator system. Whether you’re simmering sauces, preparing custards, or cooking hearty soups, the built-in MV Mixer keeps product moving, eliminates scorching, and delivers perfectly consistent results every time.
Why this kettle stands out
- Massive 80 gal. (303 L) capacity—ideal for central kitchens, commissaries, and institutional foodservice.
- 304 SS deep-drawn liner & jacket: corrosion-resistant, easy to sanitize, and built for decades of service.
- 2/3 steam jacket rated to 30 psi for faster heat-up, rapid recovery, and lower energy costs.
- Factory-installed MV Mixer with twin-shaft agitator ensures even heating and prevents product burn-on.
- Wall-mounted reinforced console boxes keep controls and plumbing tucked safely out of the work zone.
- 2" compression draw-off valve plus 1/4" perforated strainer for clog-free portioning of stocks and broths.
- Actuator-assisted bridge lift and quick-release agitator shafts speed change-overs and cleaning.
MV Mixer at a glance
- Enclosed, balanced aluminum mixer bridge with positive rim lock.
- Totally-enclosed gear motor, 2-speed operation (High / Low).
- Anchor-style 304 SS main agitator hugs kettle contour; removable nylon scrapers wipe the entire surface.
- Counter-rotating 304 SS secondary beater improves batch uniformity.
- High speed safety interlock—mixer cannot start until bridge is fully seated.
Technical specifications
| Capacity | 80 gal. (303 L) |
|---|---|
| Operating pressure | 30 psi (2.07 bar) |
| Construction | 304 stainless-steel liner, jacket, and reinforced console boxes |
| Jacket coverage | 2/3 of kettle body |
| Mounting style | Stationary, wall-console mounted (rear steam & condensate connections) |
| Agitator drive | Twin-shaft, two-speed (High 46/120 RPM • Low 23/60 RPM) |
| Mixer motor | 2 HP (high) / 1 HP (low) TEFC gear motor |
| Draw-off valve | 2" compression lever, 1/4" perforated disc strainer included |
| Steam inlet / outlet | 3/4" NPT inlet • 3/4" NPT condensate outlet |
| Certifications | ASME, NSF listed; built in the USA |
| Warranty | 12 months parts & labor (extended coverage available) |
Perfect for
- Batch cooking of soups, sauces, gravies, and stews
- Dairy and custard-based desserts that demand constant agitation
- Reduction of stocks and bone broths
- Scratch-made mashed potatoes, risottos, or polenta
Need a higher operating pressure, custom voltage, or additional accessories? Contact us for configuration assistance and lead-time information.
Product Weight:
830.0 lbFrequently Asked Questions
