Legion 60-Gallon Stationary Direct Steam Kettle with MV Twin-Shaft Mixer
Wall-console mounted • 2/3 jacket • 30 psi • 304 stainless steelDesigned for high-volume, high-precision production, this Legion 60-gallon direct steam kettle pairs a rugged 2/3 jacket with a powerful two-speed MV agitator to deliver fast, even heating and hands-free, scrape-surface mixing in one compact, wall-mounted package. From delicate sauces to heavy chowders, every recipe benefits from the kettle’s full-coverage steam jacket, counter-rotating beater and 304 stainless steel construction.
Why this kettle stands out
- 60-gallon capacity deep-drawn bowl handles large batches without hot spots.
- Full 2/3 jacket (sides & bottom) surrounds product with gentle, uniform steam heat.
- MV twin-shaft agitator with two operating speeds: low 23 RPM / 60 RPM and high 46 RPM / 120 RPM (main / secondary) for perfect product consistency.
- Anchor-style main agitator plus counter-rotating beater wipe every surface— removable nylon blades prevent burn-on and cut cleanup time.
- Actuator-assisted mixer lift & bridge tilt-out for easy kettle access and sanitation.
- 2 in. draw-off valve with ¼ in. perforated disk strainer speeds draining while catching solids.
- Wall-console mounting keeps floors clear and routes all steam & condensate connections out the rear for a clean, professional installation.
- 304 stainless steel liner, jacket and reinforced console boxes built for years of corrosion-free service.
- ASME shop-stamped for 30 psi operating pressure and NSF compliant for food safety.
- Made in the USA and backed by Legion’s limited 12-month warranty.
Technical specifications
| Capacity | 60 gal | 227 L |
|---|---|
| Heating source | Direct steam (external steam supply required) |
| Jacket coverage | 2/3 (side & bottom) |
| Working pressure | 30 psi @ 275 °F / 135 °C |
| Construction | 304 stainless steel liner, jacket & console; one-piece deep-drawn bowl |
| Agitator type | MV twin-shaft, two-speed, bayonet-mounted (quick-release) |
| Agitator motor | 2 HP (high) / ¾ HP (low) totally-enclosed gear motor |
| Mixing speeds | Main 46 / 23 RPM | Secondary 120 / 60 RPM |
| Draw-off valve | 2 in. compression, ¼ in. perforated disk strainer included |
| Mounting | Wall-console (reinforced stainless boxes, rear steam & condensate connections) |
| Certifications | ASME, NSF, UL (motor), CSA where applicable |
| Origin | Made in USA |
Ideal applications
- Soups, sauces & gravies
- Custards, puddings & confectionery fillings
- Chili, stews & chowders up to 80,000 cP
- Batch cooking for commissaries, central kitchens & institutions
Requires 30 psi clean steam supply, ½ in. condensate return, and sufficient wall support per Legion installation instructions (not included).
