Legion 50-Gallon Stationary Direct Steam Kettle with Integrated Mixer
2/3-Jacket • 304 SS Liner • 30 psi • 2″ Draw-Off ValveBuilt for high-volume production, this Legion kettle couples rapid, even steam heating with a heavy-duty twin-shaft agitator—freeing your team from hand-stirring and boosting batch consistency in every cook-run.
Key Advantages
- Ample 50 gal. (189 L) capacity for soups, sauces, fillings and stews
- 2/3 jacketed construction distributes steam over sides and bottom for faster heat-up & fewer hot spots
- Food-safe 304 stainless steel liner—seam-free, deep-drawn and polish-finished for effortless clean-up
- Integrated twin-shaft mixer:
- Anchor-style main agitator contoured to kettle wall
- Counter-rotating stainless beater breaks up particulates
- Removable nylon scraper blades keep surfaces spotless
- Two-speed gear motor (Low 23 RPM / High 46 RPM main shaft)
- Actuator-assisted bridge lift with positive rim lock
- 2″ compression draw-off valve with ¼″ perforated disk strainer for chunk-free portioning
- Stainless steel reinforced wall console hides rear steam & plumbing connections—no floor clutter
- 30 psi operating pressure handles demanding production schedules
- All-stainless exterior resists corrosion and maintains a professional, easy-sanitize finish
Specification Snapshot
| Capacity | 50 gal. (189 L) |
|---|---|
| Mounting | Stationary, wall-console mounted |
| Heat Source | Direct external steam (customer supplied) |
| Jacket Coverage | 2/3 (sides & bottom) |
| Operating Pressure | 30 psi / 207 kPa |
| Interior Liner | 304 stainless steel |
| Exterior & Console | 304 stainless steel, fully welded |
| Agitator Type | Twin-shaft anchor & counter-rotating beater |
| Agitator Speeds* | Low 23 RPM • High 46 RPM (main shaft) |
| Motor | Totally-enclosed gear motor, 2 HP (high) |
| Draw-Off Valve | 2″ compression, ¼″ perforated strainer disk |
| Steam Connection | Rear NPT (inside console) |
| Standards | ASME, NSF compliant |
*Based on standard 15 : 1 gear head ratio and 2.6 : 1 main agitator / secondary beater ratio.
Perfect For
- Hearty chowders & soups
- Custards, puddings & pastry creams
- Bolognese, chili & thick sauces
- Scrambled eggs, oatmeal & breakfast grits
- Small-particle fillings & reductions
Proudly manufactured in the USA by Legion Industries—delivering premium stainless-steel cooking solutions since 1897.
