Legion LTWC-40MV Steam Kettles
Description
Legion 40-Gallon Direct Steam Kettle with Twin-Shaft Mixer
Stationary • Wall-Console Mounted • 2/3 Jacket • 30 psiEngineered for high-volume, high-precision production, the Legion 40-gallon stationary kettle couples rapid, even steam heat with a factory-installed MV twin-shaft agitator. From silky sauces to chunky chillis, you’ll enjoy flawless results, faster cook times and easier clean-up—all in one rugged, wall-mounted unit.
Premium Construction
- 304 stainless steel deep-drawn bowl and jacket for unmatched durability and corrosion resistance.
- 2/3 jacket design delivers full-side heat coverage for faster, more even cooking.
- 30 psi operating pressure handles a wide range of production needs.
- 2" compression draw-off valve with removable ¼" perforated disk strainer for effortless portioning and drainage.
- Stainless steel reinforced console boxes mount flush to the wall—rear steam & condensate connections keep the floor clear.
Integrated MV Twin-Shaft Agitator
- Balanced aluminum bridge with totally enclosed gear-motor—built to run cool, quiet and safe.
- Two-speed drive (23 / 46 RPM) lets you switch from gentle folding to vigorous mixing at the touch of a switch.
- 304 stainless anchor agitator hugs the kettle wall; removable nylon scraper blades wipe the surface continuously to prevent scorching.
- Counter-rotating secondary beater (60 / 120 RPM) keeps particulates in suspension for perfect consistency.
- Bayonet-mounted tools lift out in seconds for cleaning or when the kettle is used without mixing.
- Actuator-assisted bridge lift with positive rim-lock and built-in safety that prevents high-speed starts while the bridge is raised.
Specs at a Glance
| Capacity | 40 gal | 151 L |
|---|---|
| Bowl Material | 304 stainless steel, deep-drawn |
| Jacket Type / Coverage | Direct steam, 2/3 jacket |
| Operating Pressure | 30 psi max |
| Draw-off Valve | 2" compression with ¼" perforated strainer |
| Mounting | Stainless wall console, rear plumbing |
| Agitator Type | MV twin-shaft, two-speed |
| Main Agitator Speed | Low 23 RPM • High 46 RPM |
| Secondary Beater Speed | Low 60 RPM • High 120 RPM |
| Motor Power | ¾ HP (low) / 1½ HP (high) |
| Country of Origin | Made in USA |
Built for Everyday Efficiency
- Deep-drawn bowl allows complete product removal and simplified cleaning.
- Perforated strainer basket protects plumbing and speeds liquid transfer.
- All food contact surfaces meet NSF standards for sanitation.
- ASME-stamped pressure vessel with Legion’s industry-leading workmanship warranty.
Need a different capacity, tri-basket insert or higher PSI rating? Contact us—Legion can configure the kettle to match virtually any production requirement.
