Legion 30-Gallon Direct Steam Kettle with Integrated Twin-Shaft Mixer
Model LTWC-30 MV · 2/3 Jacket · Wall-Console Mounted · 30 psiBuilt for demanding production kitchens, this 30-gallon stationary kettle delivers rapid, even heating and continuous hands-free agitation in one rugged, space-saving unit. Legion’s deep-drawn 304 stainless steel construction, high-efficiency steam jacket and powerful two-speed MV mixer help you cook, mix and serve high-quality batches with unmatched consistency.
Key Features
- 30 gal (114 L) working capacity—ideal for soups, sauces, custards & high-viscosity recipes.
- 2/3 steam jacket rated 30 psi for fast heat-up to approximately 275 °F (135 °C).
- Twin-shaft MV mixer head with two-speed gear motor:
- Low: ½ HP · 23 RPM main agitator · 60 RPM secondary beater
- High: 1 HP · 46 RPM main agitator · 120 RPM secondary beater
- 304 SS anchor-style main agitator contoured to kettle wall; removable nylon blades continuously scrape for scorch-free results.
- Counter-rotating 304 SS beater thoroughly incorporates solids and suspends particulates.
- Actuator-assisted lift raises agitator & bridge; positive rim-lock and safety interlock stop mixing when lifted.
- 2″ compression draw-off valve with ¼″ perforated stainless strainer for smooth, debris-free dispensing.
- Reinforced stainless steel console boxes with rear steam & condensate connections keep plumbing out of the work zone.
- Sanitary, one-piece 304 SS kettle body—no rolled edges or crevices to trap food soil.
- Made in the USA and built to meet or exceed ASME & NSF standards.
Recommended Applications
- Stocks, chowders & chili
- Tomato, cream & béchamel sauces
- Gravies & reductions
- Custards, puddings & pastry creams
- Polenta, mashed potatoes & other thick sides
Technical Specifications
| Capacity | 30 gal / 114 L |
|---|---|
| Operating Pressure | 30 psi (207 kPa) |
| Jacket Coverage | 2/3 of kettle body |
| Liner & Jacket Material | 304 stainless steel |
| Kettle Interior | 23 ″ Ø × 20.3 ″ deep (584 mm × 516 mm) |
| Draw-Off Valve | 2 ″ compression type with ¼ ″ perforated strainer |
| Mixer Type | Fixed-mount twin-shaft agitator, tilt-out bridge |
| Mixer Motor | Two-speed, totally enclosed gear motor (½ HP low / 1 HP high) |
| Agitator Speeds | 23 & 46 RPM (main) · 60 & 120 RPM (secondary) |
| Steam Connections | ¾ ″ NPT inlet & outlet (rear console) |
| Mounting | Stationary, wall-console mounted with reinforced stainless boxes |
| Certifications | ASME, NSF |
Dimensions, motor data and connection sizes are provided by Legion Industries and are subject to change without notice. Always verify utilities and clearances with your installer before ordering.
Need a different size, faucet assembly or accessories? Contact our equipment specialists for custom configurations and volume pricing.
Product Weight:
648.0 lbFrequently Asked Questions
