Legion 20-Gallon Stationary Direct Steam Kettle with Twin-Shaft Mixer
Wall-Console Mounted • 304 Stainless • 2/3 Jacket • 30 psiProduce consistent, kettle-cooked results without babysitting the pot. This 20-gallon Legion direct steam kettle pairs rapid, even heating with a factory-installed MV twin-shaft mixer so you can simmer, sauté, braise or confection with total confidence—every shift, every batch.
Key Advantages
- 20 gal. deep-drawn kettle body ideal for medium-volume production.
- 304 stainless steel liner, jacket and console resist corrosion and chemicals.
- 2/3 steam jacket (30 psi) delivers fast heat-up and tight temperature control.
- MV mixer bridge offers two selectable speeds to match product viscosity.
- Anchor-style main agitator plus counter-rotating beater eliminate hot spots.
- Nylon scraper blades wipe the entire interior surface every revolution.
- Actuator-assisted bridge lifts clear for ingredient addition & CIP cleaning.
- 2" compression draw-off valve with ¼" perforated strainer handles soups through stews while capturing large solids.
- Space-saving stainless wall console with rear steam/condensate ports keeps floor space open and service lines hidden.
- Built, tested and stamped in the USA to ASME & NSF standards.
Technical Specifications
| Capacity | 20 gallons (76 L) |
|---|---|
| Operating Pressure | 30 psi (max.) |
| Jacket Coverage | 2/3 kettle body |
| Construction | 304 SS liner, jacket, console & exterior |
| Mounting | Wall-console with stainless reinforced boxes |
| Steam Connections | Rear NPT inlet & outlet |
| Agitator Type | MV twin-shaft, tilt-out bridge |
| Agitator Speeds | High: 46 RPM main / 120 RPM secondary Low: 23 RPM main / 60 RPM secondary |
| Motor Power | 1 HP (high) / ½ HP (low) TEFC gear motor |
| Gear Ratios | Main 15:1 • Secondary/Main 2.6:1 |
| Draw-Off Valve | 2" compression, lever handle |
| Strainer | ¼" perforated removable disk |
| Certifications | ASME code stamped, NSF-listed |
| Origin | Made in the USA |
Perfect For
- Broths, stocks & soups
- High-volume sauces & gravies
- Custards, puddings & dessert bases
- Chili, stews & braises
- Rice, pasta & starch cook-downs
What’s Included
- Twin-shaft MV mixer head with actuator-assisted lift
- 304 SS anchor agitator, counter-rotating beater & nylon scrapers (quick-release)
- 2" draw-off valve & ¼" perforated strainer
- Wall console mounting kit & rear plumbing ports
- Operator’s manual & factory test report
- 12-month parts & labor warranty
Looking for additional accessories—faucets, water meters, higher-pressure jackets or insulation jackets? Reach out and our equipment specialists will customize a Legion kettle package to your exact production needs.
Product Weight:
609.0 lbFrequently Asked Questions
