Legion LTWC-100MV Steam Kettles
Description
Legion 100-Gallon Stationary Direct Steam Kettle with Twin-Shaft Mixer
Wall-Console Mounted • 2/3 Jacket • 30 psi Operating PressureBuilt for the high-output demands of commissaries, central kitchens and correctional facilities, the Legion LTWC-100 kettle with factory-installed MV series twin-shaft mixer delivers rapid, even heating and dependable hands-free agitation for batches up to 379 L. 100 % 304 stainless steel construction, rear-fed utilities and a powerful two-speed agitator system provide the rugged reliability you need shift after shift.
Kettle highlights
- Deep-drawn 100 gal (379 L) kettle body with food-grade 304 SS liner.
- 2/3 jacket design surrounds sidewalls and bottom for uniform heat transfer.
- ASME-stamped 30 psi rating—ideal for most central steam supplies.
- 2 in. compression draw-off valve for fast, clog-free discharging.
- Supplied with removable ¼ in. perforated disk strainer.
- Stainless, reinforced wall console boxes keep plumbing connections hidden at the rear.
- One-piece domed cover (actuator-assist optional) conserves energy and maintains sanitation.
- NSF-listed construction; built, tested and certified in the USA.
Integrated MV twin-shaft mixer
- Balanced aluminum bridge with safety interlock—mixing stops whenever the bridge is raised.
- Totally enclosed gear motor, two-speed operation:
- Low: 1 HP • 23 RPM main agitator / 60 RPM secondary beater
- High: 2 HP • 46 RPM main agitator / 120 RPM secondary beater
- Anchor-style 304 SS main agitator hugs kettle contour for complete batch movement.
- Counter-rotating 304 SS secondary beater accelerates blending and heat exchange.
- Removable nylon scraper blades continuously wipe the kettle wall—no scorching, easier clean-up.
- Bayonet-mount agitator & beater detach in seconds when the kettle is used without mixing.
- Actuator-assisted lift for bridge, agitator and scrapers simplifies change-over and sanitation.
- Positive rim lock & latch prevent bridge bounce during heavy or high-speed loads.
Technical specifications
| Capacity | 100 gal / 379 L |
|---|---|
| Liner material | 304 stainless steel |
| Jacket coverage | 2/3 (bottom & sidewalls) |
| Operating pressure | 30 psi (2.1 bar) max |
| Draw-off valve | 2 in. compression, with ¼ in. perforated disk strainer |
| Steam inlet / outlet | ¾ in. NPT (rear console) |
| Mounting style | Stationary, wall-console mounted |
| Mixing motor | Two-speed TEFC, 1 HP (low) / 2 HP (high) |
| Main agitator | Anchor type, 304 SS, nylon scraper blades |
| Secondary beater | Counter-rotating, 304 SS |
| Electrical | Select 115 V / 208 V / 230 V / 460 V, 1- or 3-phase, 50/60 Hz |
| Compliance | ASME, NSF |
| Country of origin | USA |
Why Legion?
- Deep-drawn kettle manufacturing since 1897—no stress points, fewer welds.
- U.S.-sourced stainless and components for maximum durability.
- Supported by a nationwide service network and 12-month parts & labor warranty.
Looking for additional automation, higher pressures or alternate capacities? Reach out to our team for custom-engineered solutions.
