Legion 80-Gallon Insulated Direct Steam Kettle w/ 2-Speed Mixer
Model LTI-80-MV • Made in the USAGive your high-volume kitchen a true production workhorse. Legion’s 80-gallon Insulated Direct Steam Kettle pairs a rugged, 2-speed twin-shaft mixer with the legendary durability of a seamless 304 stainless steel kettle body. From scratch soups and sauces to delicate custards and reductions, you’ll enjoy faster heat-up, even cooking and hands-free agitation—all while keeping operators safe and energy costs in check.
Key Performance Advantages
- Seamless deep-drawn 304 stainless steel liner eliminates rolled rims and hard-to-clean crevices.
- 2/3 jacketed design delivers rapid, uniform heat transfer with 30 psi operating pressure.
- Full body insulation (Insulated for Safety™) keeps exterior surfaces cool and reduces energy loss.
- Integrated twin-shaft agitator (high: 2 HP / 46 RPM • low: 1 HP / 23 RPM) with counter-rotating beater and removable nylon scrapers—perfect for products of varying viscosity.
- Actuator-assisted bridge & agitator lift for quick kettle access and easy cleaning.
- Front-mounted steam control valve with rear steam/condensate connections keeps the operator area uncluttered.
- 2" compression draw-off valve with 1/4" perforated stainless strainer allows fast, clog-free dispensing.
- One-piece 304 stainless domed cover (actuator-assisted) contains steam and minimizes evaporative loss.
- Four 2" diameter stainless legs with reinforcing bracing and adjustable flanged feet for rock-solid, level installation.
- Complies with ASME, NSF and other applicable agency standards.
Why Choose a Legion MV Mixer Kettle?
- Enclosed, balanced aluminum mixer bridge—no exposed belts or pulleys.
- Bayonet-mount agitator & beater pop out in seconds for sanitizing or when kettle is used without mixing.
- Safety interlock prevents high-speed starts with the agitator out of position.
- Tilt-out mixer head and positive rim-lock reduce operator strain and speed batch change-overs.
Technical Specifications
| Capacity | 80 gal / 303 L (working) |
|---|---|
| Kettle Construction | Seamless 304 stainless liner • 304L deep-drawn jacket • 304 outer casing |
| Jacket Coverage | 2/3 kettle body |
| Operating Pressure | 30 psi (steam) |
| Insulation | Full fiber insulation between jacket & outer casing |
| Agitator Motor | 2 HP (high) / 1 HP (low) • 2-speed gear motor, totally enclosed |
| Agitator Speeds | Main: 46 / 23 RPM • Secondary beater: 120 / 60 RPM |
| Draw-Off Valve | 2" 304 stainless compression type w/ 1/4" perforated strainer disc |
| Cover | One-piece domed stainless cover, actuator-assisted lift |
| Mounting | Stationary, four stainless legs, adjustable flanged feet |
| Overall Dimensions* | W 32.5" • D 39.6" • H 85.6" (to top of open cover) |
*Dimensions taken from manufacturer’s spec sheet; verify clearances before installation.
Ideal Applications
- Central kitchens & commissaries
- School nutrition programs
- Hospital & long-term care facilities
- High-volume restaurants & catering operations
Included in the Box
- Legion LTI-80 2/3 Jacketed Steam Kettle
- MV series 2-speed twin-shaft mixer assembly
- One-piece domed cover
- 2" perforated strainer disc
- Owner’s & installation manual
Product Weight:
1100.0 lbFrequently Asked Questions
