Legion LTI-60MV 60-Gallon Insulated Direct Steam Kettle with Twin-Shaft Mixer
Stationary • 2/3 Jacket • 30 psi • 304 Stainless Steel • Made in USAEngineered for large-batch production, the Legion LTI-60MV combines a 60-gallon, fully insulated, 2/3-jacketed steam kettle with a powerful two-speed agitator. Seamless stainless construction, rapid heat transfer and continuous scraping action cut cook times, prevent scorching and deliver perfectly uniform results—shift after shift.
Features & Benefits
- Seamless 304 SS deep-drawn kettle liner—no interior welds, no crevices.
- 2/3 steam jacket (304L stainless) for fast, even heating up to 30 psi.
- “Insulated for Safety”™ full-body mineral-wool insulation reduces energy loss and protects operators.
-
Mixer Package (MV twin-shaft)
- Two-speed gear motor designed for 40-100 gal kettles.
- Anchor-style main agitator with removable nylon scrape blades sweeps the entire wall & floor.
- Counter-rotating secondary beater breaks apart particulates for homogenous consistency.
- Bayonet-mount agitators & beater lift off without tools for lightning-fast cleaning.
- Actuator-assisted domed cover and bridge lift—safe, one-handed operation.
- Front-mounted steam control; rear ¾" NPT steam inlet & ½" NPT condensate return for tidy installations.
- 2" compression draw-off valve with ¼" perforated disk strainer—perfect for chunk-free portioning.
- Four 2" dia. adjustable flanged legs with cross-bracing provide rock-solid stability.
- NSF & ASME certified; fabricated and tested in Waynesboro, GA.
Technical Specifications
| Model | LTI-60 with MV Twin-Shaft Mixer |
|---|---|
| Capacity | 60 gal / 227 L |
| Operating Pressure | 30 psi (steam) |
| Jacket Coverage | 2/3 of kettle body |
| Construction | All 304 SS liner, jacket, outer casing, legs & hardware |
| Insulation | Full-body mineral wool |
| Draw-Off | 2" compression valve w/ ¼" perforated strainer |
| Cover | One-piece, actuator-assisted, domed 304 SS |
| Mixer Speeds | Low 23/60 RPM • High 46/120 RPM (main/secondary) |
| Mixer Motor | Totally enclosed gear drive – ¾ HP (low) / 2 HP (high) |
| Utility Connections | Steam inlet: ¾" NPT • Condensate return: ½" NPT (rear) |
| Footprint (W × D) | 29.5" × 36.4" (to draw-off) |
| Overall Height | 64.9" cover open • 79.1" mixer raised |
| Country of Origin | USA |
Perfect For
- Soups, chowders & sauces
- Chili, beans & stews
- Custards, puddings & pastry creams
- Fruit fillings & purees
- Any medium- to high-viscosity recipe requiring continuous agitation
Looking for alternate voltages, faucet kits or auto-fill options? Contact us for factory-installed accessories and customizations.
Product Weight:
895.0 lbFrequently Asked Questions
