Legion LTI-20MV Steam Kettles
Description
Legion LTI-20 Stationary Direct Steam Kettle with Integrated Mixer – 20 Gal.
2/3-Jacketed • Fully Insulated • 304 Stainless Steel • Made in USAEngineered for high-volume, high-precision cooking, the 20-gallon Legion LTI-20 combines the unbeatable heat transfer of a 2/3 steam jacket with a factory-mounted, twin-shaft agitator. From simmering delicate sauces to handling thick chowders, this all-stainless kettle keeps product moving, eliminates hot spots, and lets your team focus on flavor instead of stirring.
Why You’ll Love It
- Seamless 304 SS kettle liner and 304L jacket for maximum corrosion resistance.
- Full-body insulation (Insulated for Safety™) keeps exterior cool and cuts energy costs.
- Twin-shaft, two-speed agitator (23 / 46 RPM main • 60 / 120 RPM secondary) blends everything from broths to high-viscosity fillings.
- Removable nylon scraper blades sweep the entire kettle surface for exceptional heat transfer & easy cleaning.
- Heavy-duty 2" compression draw-off valve with ¼" perforated disk strainer for fast, clog-free draining.
- Four 2" diameter legs with adjustable flanged feet and cross-bracing provide rock-solid stability.
- Simple front-mounted steam control valve; rear steam/condensate connections keep the workspace clear.
- Built, tested and certified to ASME, NSF and other applicable standards.
Technical Specifications
| Capacity | 20 gal / 76 L (working) |
|---|---|
| Operating Pressure | 30 psi (steam jacket) |
| Jacket Coverage | 2/3 of kettle body |
| Construction | All 304 & 304L stainless steel, deep-drawn & seam-welded |
| Insulation | Full mineral-wool blanket between jacket & outer casing |
| Agitator Type | Twin-shaft; anchor-style main paddle + counter-rotating secondary beater |
| Agitator Speeds | Low 23/60 RPM • High 46/120 RPM (main/secondary) |
| Motor | Totally-enclosed gear motor, 1 HP high / ½ HP low |
| Draw-Off Valve | 2" compression type, 304 SS, with ¼" perforated strainer |
| Footprint (WxDxH) | Approx. 22" × 31" × 63" (refer to dimensional drawing) |
| Certifications | ASME, NSF, UL (electrical), and others as applicable |
| Country of Origin | USA |
What’s Included
- Factory-installed mixer assembly with actuator-assisted lift.
- 2" draw-off valve + ¼" perforated disk strainer.
- Adjustable flanged feet & mounting hardware.
- User/installation manual.
Popular Add-Ons (sold separately)
- Single or dual water fill faucet with swing nozzle.
- 48" flexible rinse/spray hose.
- Basket inserts or nylon bag kit for stock production.
- Automatic water meter or pressure-reducing valve.
Legion Industries continuously refines its products; specifications are subject to change without notice.
