Legion LTCRE-80 Steam Kettles

Legion LTCRE-80 Electric Coffee Kettle – 80 gal / 36 kW

Serve crowds with confidence. The LTCRE-80 brews roughly 1,280 eight-ounce cups of coffee per batch while its 2/3 steam jacket and 36 kW electric elements maintain rock-solid temperatures for maximum flavor extraction. The fully-insulated cabinet stays cool to the touch, protecting staff and conserving energy in high-volume kitchens, stadiums, correctional facilities, hotels and commissaries.

Why It Stands Out

• Heavy-Duty 304 Stainless Build – liner, jacket, draw-off tube, cover, control console and legs resist corrosion and harsh cleaners.
• 36 kW Electric, 2/3 Steam Jacket – powerful, even heating with Insulated for Safety™ outer shell.
• Automatic Recirculation Pump – built-in timer plus manual override keeps grounds fully agitated for balanced extraction.
• Graduated Sight Glass – break-resistant tube shows real-time coffee level at a glance.
• 2 in. Compression Draw-Off Valve – fast, clog-free dispensing through a 304 SS tube.
• Canvas Coffee Bag System – gridded riser basket, stainless spreader ring and removable bag for easy cleaning & re-use.
• Integrated Bag Hoist – lifts the saturated bag clear of the brew for drip-off and mess-free disposal.
• Four 2 in. Dia. Legs – welded sockets, cross-bracing and adjustable flanged feet level the kettle on uneven floors.
• 30 psi Rated Jacket – certified to ASME standards for safe operation up to 30 psi (125 gal & under).

Simple, Repeatable Workflow

• Fill – connect water to the ½ in. NPT inlet; jacket automatically heats to set temperature.
• Load Grounds – install the spreader ring & canvas bag in the riser basket, then hoist into position.
• Recirculate – set the pump timer for active circulation or switch to manual for continuous flow.
• Serve – open the 2 in. draw-off valve for rapid, splash-free service.
• Clean – swing-away dome cover, removable bag and sloped liner speed end-of-day sanitation.

Technical Specifications

*Dimensions from manufacturer drawing; allow standard installation clearances.

What’s in the Box

• LTCRE-80 insulated coffee kettle (pre-wired, factory-tested)
• Canvas coffee bag with stainless spreader ring
• Riser basket & bag hoist assembly
• Graduated sight glass (installed)
• Operation & maintenance manual

Popular Accessories (Sold Separately)

• Elevated swing-spout faucet for remote dispensing
• Stainless mesh cloth coffee filter (re-usable)
• Draw-off drain hose – 6 ft
• Pressure switch kit & remote coffee fill hardware
