Legion LTCRE-40 Steam Kettles
Description
Legion LTCRE-40 Electric Coffee Kettle 40-Gallon | 12 kW | Insulated 2/3-Steam Jacket
Brew, hold, and dispense up to 40 gallons of rich, consistent coffee with Legion’s USA-built LTCRE-40. Engineered for demanding high-volume operations, this self-contained kettle couples rugged 304 stainless construction with energy-efficient 2/3 steam-jacket heating and built-in insulation for a safer, cooler exterior.
Why You’ll Love It
- High-capacity brewing – 40 gal (151 L) batch size keeps cafeterias, correctional facilities, casinos, and banquets supplied for hours.
- Precision extraction – Recirculating pump with automatic timer and manual override guarantees uniform flavor throughout the batch.
- Durable, food-safe build – 304 stainless liner, jacket, draw-off tube, legs, and seam-welded control console resist corrosion and clean easily.
- Insulated for Safety™ – Factory-installed fiberglass insulation reduces heat loss and keeps the exterior touch-safe.
- Easy bag handling – Gridded riser basket, canvas coffee bag with stainless spreader ring, plus a built-in hoist make loading and removing grounds effortless.
- Crystal-clear monitoring – Graduated, break-resistant sight glass lets staff confirm volume at a glance.
- Fast, sanitary dispensing – 2 in. compression draw-off valve in welded 304 stainless provides smooth, clog-free flow.
- Field-friendly setup – Adjustable flanged feet level the kettle on uneven floors; ½ in. NPT water fill coupling simplifies installation.
Technical Specifications
| Model | LTCRE-40 (Self-Contained, Electric) |
|---|---|
| Capacity | 40 gal / 151 L |
| Heating Power | 12 kW electric element |
| Steam Jacket | 2/3 coverage, 30 psi operating pressure |
| Liner & Jacket | 304 & 304L stainless steel, deep-drawn |
| Draw-Off Valve | 2 in. 304 stainless compression type |
| Controls | Automatic recirculation timer, manual pump override, power switch |
| Electrical (per leg) | 208 V 1 Ø 57.7 A | 208 V 3 Ø 33.3 A | 240 V 1 Ø 50.0 A | 240 V 3 Ø 28.9 A | 480 V 3 Ø 14.4 A |
| Dimensions (WxDxH) | 28.9 in × 54.6 in × 70.5 in * (overall) |
| Legs / Base | Four 1 5/8 in. dia. stainless legs, reinforced bracing, adjustable flanged feet |
| Included Accessories | Canvas coffee bag, stainless spreader ring, riser basket, bag hoist |
| Origin | Made in USA |
*Height shown with domed cover closed.
Popular Options & Accessories (Sold Separately)
- Lockable lid and/or control cover for high-security installations
- Elevated swing-arm draw-off faucet (½ in.)
- Remote coffee fill kit
- Stainless mesh cloth coffee filter
- Draw-off drain hose (6 ft)
- Factory care & maintenance kit
Warranty
Backed by Legion’s standard 12-month parts & labor warranty from date of installation (15 months from shipment). Extended coverage available.
Legion continually improves products; specifications are subject to change without notice.
